A 10W RGB smart spotlight that supports WiFi and Bluetooth, allowing you to control lighting, color, and brightness via a smartphone app or voice commands.
Key Features:
Remote control via smartphone app
Supports WiFi and Bluetooth
Compatible with Amazon Alexa and Google Assistant
Adjustable colors and brightness
Scheduling for auto on/off lighting
Specifications:
Color Options: RGB multicolor
Power Requirements: 220–240V ~ 50/60Hz
Other Specs: 120° beam angle, IP44 protection rating
The Dahua DHI-NVR608H-128-XI is a high-performance 128-channel network video recorder (NVR) from the WizMind series, designed for large-scale IP surveillance applications. It supports advanced AI features, including face recognition, perimeter protection, and smart motion detection, making it ideal for enterprise-level security systems.
Key Features:
Supports up to 128 IP camera inputs
AI by Recorder: 8-channel face detection and recognition, 8-channel metadata, 32-channel perimeter protection, 32-channel SMD Plus
AI by Camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 64 channels
Max. decoding capability: 32 × 1080p@30 fps
Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Supports N+M cluster, RAID 0/1/5/6/10, and iSCSI
Drawer-like chassis design allows for HDD hot swapping
Supports EPTZ, One-click Arming & Disarming
Security baseline 2.3
Specifications:
Dimensions: 444 mm × 459.6 mm × 95 mm
Weight: 6.4 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 100–240 V AC, 50–60 Hz, <18 W (without HDD)
Other Specs:
Video Input: 128 channels
Alarm Input/Output: 16/8 channels
Audio Input/Output: 1/1 channel
Video Output: 4 HDMI, 2 VGA
USB Ports: 2 × USB 2.0, 2 × USB 3.2 Gen 1 Type-A
Ethernet Ports: 2 × RJ-45 (10/100/1000 Mbps)
eSATA Ports: 1
HDD Bays: 8 SATA interfaces, up to 16 TB per HDD
Operating Temperature: -10°C to 55°C
Operating Humidity: 10% to 93% (non-condensing)
Certifications: CE, FCC
The Dahua DHI-NVR616H-128-XI is a high-performance 128-channel network video recorder from the WizMind series, designed for large-scale surveillance applications. It supports advanced AI features such as face detection, perimeter protection, and SMD Plus, ensuring intelligent and efficient video monitoring.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 32 × 1080p@30 fps
Maximum 1280 Mbps incoming, 1280 Mbps recording, and 1024 Mbps outgoing bandwidth
Supports IP cameras with resolutions up to 32 MP
AI by recorder: 8-channel face detection and recognition, up to 40 face databases and 300,000 face images; 8-channel metadata; 32-channel perimeter protection; 32-channel SMD Plus
AI by camera: supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 64 channels
Supports N+M cluster, RAID 0/1/5/6/10, and iSCSI
Drawer-like chassis design allows for HDD hot swapping
Supports EPTZ, one-click arming & disarming
Security baseline 2.3
Specifications:
Dimensions: 485 mm × 133.2 mm × 508.3 mm
Weight: Approximately 11.95 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: AC 100–240V, 50/60Hz
Other Specs:
16 SATA III ports, each supporting up to 10 TB HDD
4 HDMI (HDMI3 up to 8K) and 2 VGA video outputs
Supports various network protocols including HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Registration, iSCSI
Browser support: Chrome, IE, Safari, Edge, Firefox
The Dahua NVR2216-16P-I is a 16-channel network video recorder featuring 16 PoE ports and integrated WizSense AI technology. It supports up to 12MP resolution, advanced AI functions like face detection and perimeter protection, and offers a user-friendly interface for efficient surveillance management
Key Features:
16-channel IP camera input
16 PoE ports for power and data transmission
Supports H.265/H.264/Smart H.265+/Smart H.264+/MJPEG video compression
Max decoding capability: 6 × 1080p@30fps
AI functions: 1-channel face detection and recognition, 2-channel perimeter protection, 4-channel SMD Plus
Supports up to 10 face databases and 5,000 face images
Simultaneous HDMI (up to 4K) and VGA video output
Supports ONVIF and RTSP protocols for third-party camera integration
Remote access via mobile app
Specifications:
Dimensions: 375 mm × 329.3 mm × 53 mm
Weight: Net weight: 2.63 kg; Gross weight: 3.91 kg
Material: Metal chassis
Color Options: Black
Power Requirements: 100V–240V AC, 47Hz–63Hz, 3.5A; PoE total output: 130W, max 25.5W per port
Other Specs:
Operating temperature: –10°C to +55°C
Operating humidity: 10%–93% RH
Storage: 2 SATA ports, up to 10 TB per HDD
Network bandwidth: 200 Mbps (access), 200 Mbps (storage), 100 Mbps (forwarding)
Audio input/output: 1/1 RCA
Alarm input/output: 4/2
The Dahua DH-XVR1B16-I is a 16-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP camera inputs. It features AI Coding, Smart H.265+ compression, and SMD Plus for efficient and intelligent surveillance.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
H.265+/H.265 dual-stream video compression
Full-channel AI Coding
Up to 18 IP camera inputs, each up to 6MP
Max 64 Mbps incoming bandwidth
8-channel SMD Plus for analog channels
Auto-detection of front-camera signals
Specifications:
Dimensions: 260 mm × 231.4 mm × 47.6 mm
Weight: 0.89 kg
Material: Metal
Color Options: Black
Power Requirements: 12V DC, 2A
Other Specs:
Analog Camera Input: 16 channels, BNC
IP Camera Input: 16+2 channels, up to 6MP per channel
Video Output: 1 HDMI, 1 VGA
Audio In/Out: 1/1 RCA
Recording Resolution: Up to 6MP
Storage: 1 SATA port, up to 6TB
Network Interface: 1 RJ-45 port (10/100 Mbps)
USB Ports: 2 USB 2.0
Operating Temperature: -10°C to +55°C
Operating Humidity: 0%–90%
The Dahua DHI-NVR4216-16P-4KS2 is a 16-channel network video recorder from the Lite Series, designed for high-definition IP surveillance. It supports 4K resolution processing and advanced H.265 compression, ensuring efficient storage and high-quality video recording.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 8 × 1080p@30 fps
Maximum 160 Mbps incoming bandwidth
Supports IP cameras with resolutions up to 8 MP
16 PoE ports for easy camera installation
Supports ONVIF, CGI, and SDK for third-party camera access
Video output: 1 VGA, 1 HDMI (up to 4K)
Remote access via DMSS app for iOS and Android
Specifications:
Dimensions: 375 mm × 327.5 mm × 53 mm
Weight: 2.7 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: AC 100–240V, 50/60Hz
Other Specs:
2 SATA III ports, each supporting up to 10 TB HDD
1-channel RCA audio input and output
4 alarm inputs and 2 alarm outputs
Supports various network protocols including HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Registration
Browser support: Chrome, IE, Safari, Edge, Firefox
The Dahua DHI-NVR5216-EI is a 16-channel network video recorder from the WizSense series, designed for high-performance IP surveillance applications. It supports advanced AI features, including face recognition, perimeter protection, and Smart Motion Detection Plus (SMD Plus), making it suitable for various security scenarios.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 32 × 1080p@30 fps or 16 × 4MP@30 fps
Maximum 384 Mbps incoming/recording/outgoing bandwidth
Supports IP cameras with resolutions up to 32 MP
AI by Recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by Camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 16 channels
Supports N+M cluster and iSCSI
Specifications:
Dimensions: 375 mm × 327 mm × 53 mm
Weight: 2.6 kg
Material: Metal
Color Options: Black
Power Requirements: 100–240V AC, 50/60 Hz
Other Specs:
Video Output: 1 HDMI (up to 3840 × 2160), 1 VGA (up to 1920 × 1080)
Audio Input/Output: 1/1 RCA
Alarm Input/Output: 4/2 channels
HDD: 2 SATA ports, each supporting up to 20 TB
Network Interface: 1 × 10/100/1000 Mbps Ethernet port
USB Ports: 2 × USB 2.0, 1 × USB 3.0
Operating Temperature: –10°C to +55°C
Operating Humidity: 10%–90% RH
The Dahua DHI-NVR4216-4KS2/L is a 16-channel network video recorder from the Lite Series, designed for high-definition surveillance applications. It supports up to 8MP resolution, H.265+/H.264+ compression, and advanced AI features when paired with compatible cameras.
Key Features:
Supports up to 16 IP camera inputs.
Maximum decoding capability: 8 × 1080p@30 fps.
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats.
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD.
P2P remote surveillance, video playback on mobile devices.
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K.
Supports mainstream cameras of ONVIF and RTSP protocols.
Remote configuration and management of IPCs, including parameter settings, information retrieval, and batch upgrades.
Specifications:
Dimensions: 375 mm × 282.4 mm × 53 mm
Weight: 1.51 kg (net), 2.76 kg (gross)
Material: Metal enclosure
Color Options: Black
Power Requirements: 12 V DC, 4 A; Power consumption <10 W (without HDD)
Other Specs:
Video Input: 16 channels
Audio Input/Output: 1/1 RCA
Video Output: 1 HDMI (up to 4K), 1 VGA
USB Ports: 2 × USB 2.0 (1 front, 1 rear)
Network Interface: 1 × RJ-45 (10/100/1000 Mbps)
HDD Bays: 2 SATA III ports, up to 10 TB per HDD
Alarm Input/Output: 4/2 channels
Operating Temperature: –10 °C to +55 °C
Operating Humidity: 10%–93% (non-condensing)
Certifications: CE, FCC
The Dahua XVR5116H-4KL-I3 is a powerful 16-channel 4K digital video recorder designed for high-performance surveillance. It supports multiple video input formats and advanced AI features, making it ideal for secure and intelligent monitoring environments.
Key Features:
16-channel HDCVI/AHD/TVI/CVBS/IPC input
Up to 32-channel IP camera access (each up to 8MP)
Supports H.265+/H.265 compression
16-channel SMD Plus for analog channels
8-channel perimeter protection for analog channels
2-channel face recognition for analog channels
Supports QuickPick 2.0 and privacy protection
AI search and smart detection technology
Supports full-channel AI Coding
HDMI (up to 4K) and VGA output
Specifications:
Dimensions: 325 mm × 255 mm × 55 mm
Weight: 1.23 kg
Material: Metal
Color Options: Black
Power Requirements: 12V DC, 2A
Other Specs:
1 SATA port (up to 10 TB)
16 alarm inputs, 3 alarm outputs
Operating Temp: -10°C to +55°C
Humidity: 10%–90% RH
The Dahua DH-XVR5216AN-4KL-I3 is a 16-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features advanced AI capabilities, including perimeter protection, face recognition, and Smart Motion Detection Plus (SMD Plus). With support for up to 32 IP channels and 4K resolution, it offers comprehensive surveillance solutions.
Key Features:
Supports 16 analog channels and up to 32 IP channels (each up to 8MP)
H.265+/H.265 dual-stream video compression
AI functions: 16-channel SMD Plus, 8-channel perimeter protection, 2-channel face recognition
QuickPick 2.0 for efficient target retrieval
Privacy protection with real-time face masking
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Maximum incoming bandwidth of 128 Mbps
Specifications:
Dimensions: 375 mm × 334.4 mm × 53 mm
Weight: 1.80 kg
Material: Metal casing
Color Options: Black
Power Requirements: 100–240V AC, 50/60Hz; <15W (without HDD)
Other Specs:
Video Input: 16 BNC ports
Audio Input/Output: 1/1 RCA; 16-channel BNC (Coaxial Audio)
Video Output: 1 HDMI, 1 VGA
Storage: 2 SATA ports, up to 16TB per HDD
USB Ports: 2 (1 front USB 2.0; 1 rear USB 3.0)
Network Interface: 1 RJ-45, 10/100/1000 Mbps Ethernet port
Operating Conditions: –10°C to +55°C; 10%–90% RH
Certifications: CE, FCC
The Dahua DH-XVR1B16H-I is a 16-channel Penta-brid digital video recorder from the WizSense series, designed for high-definition surveillance applications. It supports multiple video formats and incorporates AI features for enhanced security monitoring.
Key Features:
16-channel SMD Plus for analog channels or 24-channel SMD by camera, enabling accurate human and vehicle detection.
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs.
H.265+/H.265 dual-stream video compression for efficient storage and bandwidth usage.
Supports full-channel AI Coding.
Supports up to 24 IP camera inputs, each channel up to 6MP; Max 128 Mbps incoming bandwidth.
Long transmission distance over coaxial cable.
POS functionalities for retail applications.
Specifications:
Dimensions: 260 mm × 231.4 mm × 47.6 mm
Weight: 0.93 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 12 VDC, 2 A; Power consumption <12 W (without HDD)
Other Specs:
Video Input: 16 channels (BNC)
IP Camera Input: Up to 24 channels, each up to 6MP
Audio In/Out: 1/1 RCA
Video Output: 1 HDMI, 1 VGA
USB Ports: 2 × USB 2.0
Network Interface: 1 × RJ-45 (100 Mbps)
HDD: 1 SATA port, up to 6TB capacity
Operating Temperature: –10 °C to +45 °C
Operating Humidity: 10%–90% (non-condensing)
Certifications: CE, FCC
The Dahua DH-XVR5116H-I3 is a 16-channel Penta-brid digital video recorder from the WizSense series. It supports multiple video input formats, including HDCVI, AHD, TVI, CVBS, and IP, providing flexibility for various surveillance setups. With advanced AI features like SMD Plus, perimeter protection, and face recognition, it enhances security monitoring by reducing false alarms and enabling accurate human and vehicle detection
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
Up to 16 analog channels and 8 IP channels (total of 24 channels)
Maximum 128 Mbps incoming bandwidth
Supports up to 5MP HDCVI and 6MP IP camera inputs
Smart H.265+/H.265 dual-stream video compression
16-channel SMD Plus for human/vehicle classification
4-channel perimeter protection with tripwire and intrusion detection
2-channel face recognition with up to 10 face databases and 20,000 images
Supports IoT and POS functionalities
Specifications:
Video Compression: H.265+/H.265/H.264+/H.264
Audio Compression: G.711a, G.711u, PCM
Video Outputs: 1 HDMI (up to 4K), 1 VGA (up to 1080P)
Audio Inputs/Outputs: 1/1 RCA, supports two-way talk
Recording Resolution: 5M-N, 4M-N, 1080P, 720P, 960H, D1, CIF
Playback: Up to 16 channels simultaneous playback
Storage: 1 SATA port, up to 16TB capacity
Network Interface: 1 RJ-45 port (10/100/1000 Mbps)
USB Interface: 1 USB 2.0, 1 USB 3.0
Power Supply: 12V DC, 2A
Power Consumption: <12W (without HDD)
Working Temperature: -10°C to +55°C (14°F to 131°F)
Dimensions: 325 mm × 257 mm × 55 mm
Weight: 1.15 kg (without HDD)
The Dahua XVR7216AN-4K-I3 is a 16-channel Penta-brid 4K digital video recorder from the WizSense series, designed for high-performance surveillance applications. It supports multiple video input formats, including HDCVI, AHD, TVI, CVBS, and IP, providing flexibility in system integration. With advanced AI features such as SMD Plus, perimeter protection, and face recognition, it enhances security monitoring and reduces false alarms.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
Up to 32-channel IP camera inputs, each channel up to 8MP
H.265+/H.265 dual-stream video compression
16-channel AI Coding for efficient storage and bandwidth usage
Up to 16 channels SMD Plus for accurate human and vehicle detection
12-channel perimeter protection with tripwire and intrusion detection
6-channel face recognition with a database capacity of up to 20,000 images
1-channel privacy protection for real-time face masking
Supports QuickPick 2.0 for efficient target retrieval
IoT and POS functionalities
Specifications:
Dimensions: 375 mm × 287 mm × 53 mm
Weight: 2.4 kg
Material: Metal chassis
Color Options: Black
Power Requirements: DC 12V, 5A
Other Specs:
Video Compression: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression: G.711a, G.711u, PCM
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio Input/Output: 1-channel RCA input, 1-channel RCA output
Two-way Talk: Supported (shares audio input with the first channel)
HDD Interface: 2 SATA ports, up to 16TB capacity for each disk
USB Ports: 1 front USB 2.0, 1 rear USB 3.0
Network Interface: 1 RJ-45 port (10/100/1000 Mbps)
RS-485: 1 port for PTZ control
Alarm Input/Output: 16-channel BNC (coaxial audio), 1-channel RCA output
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH (non-condensing)
Certifications: CE, FCC
The Dahua XVR7216AN-4K-I3 is a 16-channel Penta-brid 4K digital video recorder from the WizSense series, designed for high-performance surveillance applications. It supports multiple video input formats, including HDCVI, AHD, TVI, CVBS, and IP, providing flexibility in system integration. With advanced AI features such as SMD Plus, perimeter protection, and face recognition, it enhances security monitoring and reduces false alarms.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
Up to 32-channel IP camera inputs, each channel up to 8MP
H.265+/H.265 dual-stream video compression
16-channel AI Coding for efficient storage and bandwidth usage
Up to 16 channels SMD Plus for accurate human and vehicle detection
12-channel perimeter protection with tripwire and intrusion detection
6-channel face recognition with a database capacity of up to 20,000 images
1-channel privacy protection for real-time face masking
Supports QuickPick 2.0 for efficient target retrieval
IoT and POS functionalities
Specifications:
Dimensions: 375 mm × 287 mm × 53 mm
Weight: 2.4 kg
Material: Metal chassis
Color Options: Black
Power Requirements: DC 12V, 5A
Other Specs:
Video Compression: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression: G.711a, G.711u, PCM
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio Input/Output: 1-channel RCA input, 1-channel RCA output
Two-way Talk: Supported (shares audio input with the first channel)
HDD Interface: 2 SATA ports, up to 16TB capacity for each disk
USB Ports: 1 front USB 2.0, 1 rear USB 3.0
Network Interface: 1 RJ-45 port (10/100/1000 Mbps)
RS-485: 1 port for PTZ control
Alarm Input/Output: 16-channel BNC (coaxial audio), 1-channel RCA output
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH (non-condensing)
Certifications: CE, FCC
The Dahua XVR5116HS-I3 is a 16-channel Penta-brid digital video recorder designed for high-definition surveillance systems. It supports HDCVI, AHD, TVI, CVBS, and IP video inputs, offering flexibility for various camera types. With advanced AI features like SMD Plus, perimeter protection, and face recognition, it enhances security monitoring and reduces false alarms.
Key Features:
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Up to 16 analog channels and 8 IP channels (total 24 channels)
Supports up to 6MP IP camera input
H.265+/H.265 dual-stream video compression
Full-channel AI Coding
16-channel SMD Plus for analog channels
4-channel perimeter protection for analog channels
2-channel face recognition for analog channels
IoT & POS functionalities
Specifications:
Dimensions: 260 mm × 237.9 mm × 47.6 mm
Weight: 1.17 kg (net), 1.57 kg (gross)
Material: Metal enclosure
Color Options: Black
Power Requirements: DC12V, 2A; Power consumption <12W
Other Specs:
Video Outputs: 1 HDMI, 1 VGA
Audio Inputs/Outputs: 1 RCA input, 1 RCA output
Two-way Talk: Supported
HDD: 1 SATA port, up to 16TB
Network Interface: 1 RJ-45 port (10/100/1000 Mbps)
USB Ports: 1 USB 2.0, 1 USB 3.0
Operating Temperature: –10°C to +55°C
Operating Humidity: 10%–90%
The Dahua LR2218-16ET-240 is an 18-port Layer 2 managed ePoE switch designed for long-distance power and data transmission. It supports Dahua's Enhanced Power over Ethernet (ePoE) technology, enabling PoE transmission up to 800 meters over Ethernet cables. The switch offers advanced features like VLAN, QoS, and PoE management, making it ideal for surveillance systems and other network applications.
Key Features:
Supports long-distance PoE transmission up to 800 meters with ePoE technology
Ports 1–8 support three self-adaptive transmission modes: IEEE, E100, and E10
Ports 1–8 support both twisted-pair and coaxial cable transmission
Compliant with IEEE802.3af, IEEE802.3at, and Hi-PoE standards
Supports web management: port management, 802.1Q VLAN, STP/RSTP, LACP, 802.1X, QoS
PoE management features including Green PoE and Legacy Support
Conforms to IEEE802.3, IEEE802.3u, IEEE802.3ab/z, and IEEE802.3X standards
Specifications:
Dimensions: 440 mm × 300 mm × 44 mm
Weight: 3.14 kg
Material: Sheet metal
Color Options: Black
Power Requirements: 100–240V AC, 50/60 Hz
Other Specs:
Ethernet Ports: 16 × 10/100 Mbps RJ-45 PoE ports
Uplink Ports: 2 × 10/100/1000 Mbps RJ-45 and 2 × 1000 Mbps SFP combo ports
PoE Power Budget: 240W total; Ports 1–2 support up to 60W (Hi-PoE), Ports 3–16 support up to 30W each
Switching Capacity: 8.8 Gbps
Packet Forwarding Rate: 5.36 Mpps
Packet Buffer Memory: 2.75 Mb
MAC Table Size: 4K
VLAN Support: Supports up to 31 VLANs
Operating Temperature: –10°C to +55°C
Operating Humidity: 5%–95% RH
Lightning Protection: Common mode: 4KV; Differential mode: 2KV
The Dahua DHI-NVR5432-EI is a high-performance 32-channel network video recorder from the WizSense series. It supports up to 32MP IP cameras, offers advanced AI functions including face recognition, perimeter protection, and SMD Plus, and features a robust design suitable for various surveillance applications.Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Max. decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps
Max. 384 Mbps incoming/recording/outgoing bandwidth
Supports IP cameras with a resolution up to 32 MP
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 32 channels
Supports N+M cluster and iSCSISpecifications:
Dimensions: 440 mm × 415.1 mm × 70 mm
Weight: 4.74 kg
Material: Metal casing
Color Options: Black
Power Requirements: 100–240 VAC, 50–60 Hz
Other Specs:
4 SATA ports, each supporting up to 20 TB
2 HDMI and 2 VGA video outputs
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports
1 USB 2.0 port (front), 2 USB 3.0 ports (rear)
1 audio input (RCA), 2 audio outputs (RCA)
16 alarm inputs, 6 alarm outputs
Operating temperature: –10°C to +55°C
Operating humidity: 10%–93% (non-condensing)
Rack or desktop installation
Certifications: CE, FCC
The Dahua DHI-NVR4432-EI is a high-performance 32-channel network video recorder featuring advanced AI capabilities. It supports up to 4 hard drives and offers intelligent functions such as face recognition, perimeter protection, and Smart Motion Detection Plus (SMD Plus), making it ideal for comprehensive surveillance solutions.
Key Features:
Supports 32 IP camera channels
4 SATA ports supporting up to 16 TB each
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding formats
Maximum decoding capability: 16 × 1080p@30 fps
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus
AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; ANPR; people counting; stereo analysis; heat map
Supports adaptive decoding
Connected to third-party network cameras
Security baseline 2.3
Specifications:
Dimensions: 440 mm × 415.6 mm × 76 mm
Weight: 4.25 kg (net), 6.35 kg (gross)
Material: Metal casing
Color Options: Black
Power Requirements: 100–240V AC, 50/60Hz
Other Specs:
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio Input/Output: 1 RCA input, 1 RCA output
Alarm Input/Output: 16 inputs, 4 outputs
Network Interface: 2 RJ-45 ports (10/100/1000 Mbps)
USB Ports: 1 USB 2.0, 1 USB 3.0
Operating Conditions: –10°C to +55°C; 10%–93% RH
Certifications: CE, FCC
The Dahua DHI-NVR5232-16P-EI is a high-performance 32-channel network video recorder from the WizSense series. It features 16 PoE ports, supports up to 32MP IP cameras, and offers advanced AI functions including face recognition, perimeter protection, and SMD Plus.Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Max. decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps
Max. 384 Mbps incoming/recording/outgoing bandwidth
Supports IP cameras with a resolution up to 32 MP
Supports AcuPick with up to 32 channels
Supports N+M cluster
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD PlusSpecifications:
Dimensions: 375.0 mm × 327.0 mm × 53.0 mm
Weight: 2.66 kg
Material: Metal casing
Color Options: Black
Power Requirements: 100–240 VAC, 47–63 Hz
Other Specs:
2 SATA ports, up to 16 TB for each HDD
16 PoE ports (IEEE802.3af/at), total output power ≤ 130W
1 HDMI and 1 VGA output
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port
1 USB 2.0 port (front), 1 USB 3.0 port (rear)
Operating temperature: –10°C to +55°C
Operating humidity: 10%–93%
Rack or desktop installation
The Dahua DHI-NVR4232-16P-4KS2/L is a high-performance 32-channel network video recorder (NVR) with integrated 16-port PoE, designed for professional-grade surveillance systems. Supporting ultra-high-definition recording and advanced management features, this NVR is ideal for large-scale security applications.
Key Features:
Supports 32 IP camera channels
16 built-in PoE ports for direct camera connectivity
Supports H.265+/H.265/H.264+/H.264 video compression
Maximum incoming bandwidth of 200 Mbps
Supports up to 8MP resolution for preview and playback
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
Supports mainstream cameras of ONVIF and RTSP protocols
P2P remote surveillance, video play on mobile device
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
Supports remote configuration and management of IPC
Specifications:
Dimensions: 375 mm × 327.9 mm × 53 mm
Weight: Net: 2.6 kg; Gross: 3.8 kg
Material: Metal casing
Color Options: Black
Power Requirements: 100 V–240 V AC, 47–63 Hz, 3.5 A
Other Specs:
Storage: 2 SATA III ports, up to 10 TB for a single HDD
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio Input/Output: 1 RCA input, 1 RCA output
USB Ports: 2 (1 front USB2.0; 1 back USB2.0)
Network Interface: 1 RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port
PoE: 16 ports, total power 130 W, max. 25.5 W per port
Operating Conditions: –10 °C to +55 °C; 10%–93% RH
Certifications: CE, FCC
The Dahua DHI-NVR4232-4KS3 is a 32-channel network video recorder (NVR) designed for high-definition surveillance systems. Supporting up to 12MP resolution and equipped with advanced AI features, it ensures efficient video recording and intelligent analytics.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats.
Maximum decoding capability: 8 × 1080p@30 fps or 2 × 8 MP@30 fps.
Supports IP cameras with resolutions up to 12 MP.
AI by Recorder supports 2-channel SMD Plus.
AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis, and heat map.
Supports EPTZ and one-click arming and disarming.
Specifications:
Dimensions: 375 mm × 282.9 mm × 53 mm
Weight: 1.49 kg
Material: Metal casing
Color Options: Black
Power Requirements: 12V DC, 4A; Power consumption: <10W (without HDD)
Other Specs:
Operating Temperature: –10°C to +55°C
Operating Humidity: 10%–93% RH
Installation: Rack or desktop
Video Output: 1 HDMI (up to 4K), 1 VGA (up to 1080p)
Audio Input/Output: 1-channel RCA each
Alarm Input/Output: 4 inputs / 2 outputs
Disk Interface: 2 SATA ports, up to 20TB total capacity
Network Interface: 1 RJ-45 (10/100/1000 Mbps)
USB Ports: 2 (1 front USB 2.0, 1 rear USB 2.0)
Supported Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
Mobile Access: iOS, Android
Browser Support: Chrome, IE, Safari, Edge, Firefox
Interoperability: ONVIF 22.12 (Profile T/S/G), CGI, SDK
The Dahua NVR4232-4KS2/L is a 32-channel 4K Lite Network Video Recorder designed for high-definition surveillance applications. It supports up to 8MP resolution recording, H.265 compression, and AI features like face detection and perimeter protection.
Key Features:
Supports up to 32 IP camera inputs
Video compression: H.264, H.265, Smart H.264+, Smart H.265+
Maximum decoding capability: 8 × 1080p@30 fps
Supports ONVIF and RTSP protocols
AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
P2P remote surveillance via mobile devices
Simultaneous HDMI (up to 4K) and VGA video output
Specifications:
Dimensions: 375.0 mm × 282.9 mm × 53.0 mm
Weight: 1.5 kg (net), 2.6 kg (gross)
Material: Metal casing
Color Options: Black
Power Requirements: 12V DC, 4A; Power consumption: <5.6W (without HDD)
Other Specs:
Operating Temperature: –10°C to +55°C
Operating Humidity: 10%–93% RH
Installation: Desktop/Rack mount
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio Input/Output: 1-channel RCA each
Alarm Input/Output: 4 inputs / 2 outputs
Disk Interface: 2 SATA III ports, up to 10TB per HDD
Network Interface: 1 RJ-45 (10/100/1000 Mbps)
USB Ports: 2 (1 front USB 2.0, 1 rear USB 2.0)
Supported Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
Mobile Access: iOS, Android
Browser Support: Chrome, IE, Safari, Edge, Firefox
Interoperability: ONVIF (Profile T/S/G), CGI, SDK
The Dahua DH-XVR5232AN-I3 is a 32-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features advanced AI capabilities, including perimeter protection, face recognition, and Smart Motion Detection Plus (SMD Plus). With support for up to 48 IP channels and 5MP resolution, it offers comprehensive surveillance solutions.
Key Features:
Supports 32 analog channels and up to 48 IP channels (each up to 6MP)
H.265+/H.265 dual-stream video compression
AI functions: 32-channel SMD Plus, 8-channel perimeter protection, 2-channel face recognition
QuickPick 2.0 for efficient target retrieval
IoT and POS functionalities
Specifications:
Dimensions: 375 mm × 289 mm × 53 mm
Weight: 1.98 kg
Material: Metal casing
Color Options: Black
Power Requirements: 12 VDC, <17W (without HDD)
Other Specs:
Video Input: 32 BNC ports
Audio Input/Output: 1/1 RCA
Video Output: 1 HDMI, 1 VGA
Storage: 2 SATA ports, up to 16TB per HDD
USB Ports: 2 (1 front USB 2.0; 1 rear USB 3.0)
Network Interface: 1 RJ-45, 10/100/1000 Mbps Ethernet port
Operating Conditions: –10°C to +55°C; 0%–90% RH
Certifications: CE, FCC
The Dahua DHI-NVR4832-EI is a 32-channel network video recorder from the WizSense series, designed to deliver advanced AI-driven surveillance capabilities. It supports high-resolution video recording up to 16MP, intelligent analytics like face recognition and perimeter protection, and offers robust storage options with 8 SATA ports. Its compatibility with third-party cameras and adherence to ONVIF standards make it a versatile choice for comprehensive security solutions.
Key Features:
Supports up to 32 IP camera inputs
Maximum decoding capability: 16 × 1080p@30 fps
Video compression formats: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases with 20,000 images; 4-channel SMD Plus
AI by Camera: Face detection and recognition, perimeter protection, SMD Plus, ANPR, people counting, stereo analysis, heat map
Supports adaptive decoding
Security baseline 2.3
Compatible with third-party network cameras
Dual HDMI and VGA video outputs
Supports up to 8 SATA HDDs, each up to 16 TB
Alarm inputs/outputs: 16/4 channels
Operating system: Embedded Linux
Specifications:
Dimensions: 2U chassis
Material: Metal enclosure
Color Options: Black
Power Requirements: 100–240V AC, 50/60Hz
Other Specs:
Network Bandwidth: 256 Mbps (AI disabled), 180 Mbps (AI enabled)
Video Output Resolutions: HDMI: up to 3840 × 2160; VGA: up to 1920 × 1080
Audio Input/Output: 1-channel RCA input, 1-channel RCA output
Alarm Input/Output: 16 channels input, 4 channels output
USB Ports: 2 × USB 2.0, 1 × USB 3.0
Ethernet Ports: 2 × RJ-45 (10/100/1000 Mbps)
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH
The Dahua DHI-NVR1104HS-P-S3-H is a compact 4-channel network video recorder featuring Power over Ethernet (PoE) support, Smart H.265+/H.264+ video compression, and a user-friendly interface. Designed for small to medium-sized surveillance setups, it offers efficient storage, remote monitoring, and seamless integration with ONVIF-compatible cameras.
Key Features:
4-channel IP camera input
4 PoE ports with a total power budget of 36W
Supports up to 8MP resolution
Smart H.265+/H.264+ video compression
HDMI and VGA simultaneous video output (max 1080p)
Remote access via mobile app (iDMSS/gDMSS)
ONVIF and RTSP protocol support
Specifications:
Dimensions: 260mm × 225mm × 47.6mm
Weight: 0.84 kg
Material: Metal
Color Options: Black
Power Requirements: DC 48V, 1.25A
Other Specs:
Video Input: 4 IP channels
PoE Ports: 4 (10/100 Mbps)
Maximum Decoding Capability: 1-ch@8MP (30fps), 4-ch@1080p (30fps)
Storage: 1 SATA port, up to 8TB
Network Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, P2P
Mobile Access: iDMSS (iOS), gDMSS (Android)
USB Ports: 2 (1 front USB 2.0, 1 rear USB 2.0)
Operating Temperature: -10°C to +45°C
Storage Temperature: 0°C to +40°C
Operating Humidity: 10%~93%
Storage Humidity: 30%~85%
The Dahua XVR1B04H-I is a 4-channel Penta-brid digital video recorder from the Cooper-I Series, supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features AI-powered functions like SMD Plus for accurate human and vehicle detection, and AI Coding for efficient storage. With support for up to 6 IP camera inputs and Smart H.265+ compression, it offers a versatile and cost-effective surveillance solution.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
Up to 6-channel IP camera input, each up to 6MP
Smart H.265+/H.265 dual-stream video compression
4-channel SMD Plus for accurate human and vehicle detection
AI Coding for optimized storage and bandwidth usage
Supports HDMI and VGA simultaneous video output
One SATA port, up to 6TB capacity
Supports mobile remote monitoring via iOS and Android
Specifications:
Dimensions: 260 mm × 236 mm × 48 mm
Weight: 1.0 kg
Material: Metal chassis
Color Options: Black
Power Requirements: DC 12V, 1.5A
Other Specs:
Video Compression: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression: G.711a, G.711u, PCM
Video Output: 1 HDMI (up to 1080p), 1 VGA
Audio Input/Output: 1-channel RCA input, 1-channel RCA output
Two-way Talk: Supported (shares audio input with the first channel)
HDD Interface: 1 SATA port, up to 6TB capacity
USB Ports: 2 USB 2.0 ports
Network Interface: 1 RJ-45 port (10/100 Mbps)
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH (non-condensing)
Certifications: CE, FCC
The Dahua ASC2204C-D is a multifunctional access controller designed for managing up to 4 doors with 2-way access. It supports various communication protocols and offers robust security features, making it suitable for diverse access control applications.
Key Features:
Supports TCP/IP, RS-485, and Wiegand communication protocols
Manages up to 4 doors with 2-way access
Stores up to 100,000 users and 500,000 card-swiping records
Supports multi-door interlock, multi-user unlock, anti-passback, and remote unlock
Equipped with alarm features: reader tamper, intrusion, unlocking timeout, duress, invalid card threshold, and incorrect password
Built-in RTC with manual and automatic time synchronization
Data retention during power failure and supports online upgrades
Watchdog mechanism ensures operational stability
Specifications:
Dimensions: 337 mm × 272 mm × 90 mm
Weight: 3.5 kg
Material: SECC steel board
Color Options: Black
Power Requirements: 100–240 V AC
Other Specs:
User Capacity: 100,000 users
Fingerprint Capacity: 3,000 fingerprints
Card Capacity: 100,000 cards
Record Capacity: 500,000 events
Alarm Inputs: 8 digital inputs
Alarm Outputs: 8 relay outputs
RS-485 Ports: 9
Wiegand Ports: 8
Network Interface: 1 × 10/100 Mbps Ethernet port
Operating Temperature: –30°C to +60°C
Operating Humidity: 5%–95% RH (non-condensing)
Installation: Surface mount
Certifications: CE, FCC, UL
The Dahua DH-XVR5104HS-4KL-I3 is a 4-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP camera inputs. It features AI Coding, Smart H.265+ compression, and advanced AI functions like SMD Plus, perimeter protection, and face recognition for efficient and intelligent surveillance.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
H.265+/H.265 dual-stream video compression
Supports all-channel AI Coding
Up to 8 IP camera inputs, each up to 8MP
Max 64 Mbps incoming bandwidth
4-channel SMD Plus for analog channels
4-channel perimeter protection for analog channels
2-channel face recognition for analog channels
2-channel QuickPick 2.0 for analog channels
1-channel privacy protection for analog channels
IoT and POS functionalities
Specifications:
Dimensions: 260 mm × 237.9 mm × 47.6 mm
Weight: 0.96 kg
Material: Metal
Color Options: Black
Power Requirements: 12V DC, <7W (without HDD)
Other Specs:
Analog Camera Input: 4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
IP Camera Input: Up to 8 channels, each up to 8MP
Video Output: 1 HDMI (up to 4K), 1 VGA
Audio In/Out: 1/1 RCA
Recording Resolution: Up to 4K
Storage: 1 SATA port, up to 10TB
Network Interface: 1 RJ-45 port (10/100 Mbps)
USB Ports: 2 USB 2.0
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% (RH), non-condensing
The Dahua DHI-NVR5864-EI is a high-performance 64-channel network video recorder from the WizSense series, designed for large-scale surveillance applications. It supports advanced AI functions, including face detection, perimeter protection, and SMD Plus, ensuring intelligent and efficient video monitoring.
Key Features:
Supports up to 64 IP camera inputs
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding formats
Maximum decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports RAID 0/1/5/6/10
Maximum 384 Mbps incoming/recording/outgoing bandwidth
Specifications:
Dimensions: 440 mm × 89 mm × 458 mm
Weight: 6.4 kg
Material: Metal
Color Options: Black
Power Requirements: AC 100–240V, 50/60Hz
Other Specs:
Video Output: 2 HDMI (up to 4K), 2 VGA
Audio Input/Output: 1/2 RCA
Alarm Input/Output: 16/8 channels
HDD: 8 SATA ports, up to 20 TB per HDD
Network Interface: 2 RJ-45 ports (10/100/1000 Mbps)
USB Ports: 2 USB 2.0, 2 USB 3.0
AI Functions:
Face Detection: 2 channels by recorder; up to 16 channels by camera
Face Recognition: 2 channels by recorder; up to 16 channels by camera
Perimeter Protection: 4 channels by recorder; up to 16 channels by camera
SMD Plus: 8 channels by recorder; up to 16 channels by camera
Metadata: 8 channels by camera
ANPR: 8 channels by camera
People Counting: 4 channels by camera
Heat Map: 4 channels by camera
The Dahua DHI-NVR608H-64-XI is a high-performance 64-channel network video recorder (NVR) from the WizMind series, designed for large-scale IP surveillance applications. It supports advanced AI features, including face recognition, perimeter protection, and smart motion detection, making it ideal for enterprise-level security systems.
Key Features:
Supports up to 64 IP camera inputs
AI by Recorder: 8-channel face detection and recognition, 8-channel metadata, 32-channel perimeter protection, 32-channel SMD Plus
AI by Camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 64 channels
Max. decoding capability: 32 × 1080p@30 fps
Max. 1280/1280/1024 Mbps incoming/recording/outgoing bandwidth
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Supports N+M cluster, RAID 0/1/5/6/10, and iSCSI
Drawer-like chassis design allows for HDD hot swapping
Specifications:
Dimensions: 444 mm × 456.6 mm × 95 mm
Weight: 6.4 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 100–240 V AC, 50–60 Hz, <18 W (without HDD)
Other Specs:
Video Input: 64 channels
Alarm Input/Output: 16/8 channels
Audio Input/Output: 1/1 channel
Video Output: 4 HDMI, 2 VGA
USB Ports: 2 × USB 2.0, 2 × USB 3.2 Gen 1 Type-A
Ethernet Ports: 2 × RJ-45 (10/100/1000 Mbps)
eSATA Ports: 1
HDD Bays: 8 SATA interfaces, up to 16 TB per HDD
Operating Temperature: -10°C to 55°C
Operating Humidity: 10% to 93% (non-condensing)
Certifications: CE, FCC
The Dahua DH-XVR5108HS-I3 is an 8-channel Penta-brid digital video recorder from the WizSense series, supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features AI capabilities such as SMD Plus, perimeter protection, and face recognition, making it suitable for advanced surveillance applications.
Key Features:
8-channel analog video input (HDCVI/AHD/TVI/CVBS)
Supports up to 12 IP camera inputs (each up to 6MP)
H.265+/H.265 dual-stream video compression
AI functions: 8-channel SMD Plus, 4-channel perimeter protection, 2-channel face recognition
AI Coding for optimized storage and bandwidth
Supports IoT and POS functionalities
Specifications:
Dimensions: 260mm × 237.8mm × 47.6mm
Weight: 0.97kg (net), 1.39kg (gross)
Material: Metal
Color Options: Black
Power Requirements: 12V DC, 2A; Power consumption <7W (without HDD)
Other Specs:
Operating Temperature: –10°C to +55°C
Storage Temperature: –20°C to +60°C
Operating Humidity: 10%–90% (non-condensing)
Video Outputs: 1 HDMI, 1 VGA
Audio Input/Output: 1/1 RCA; Two-way talk supported
Disk Interface: 1 SATA port, up to 16TB
Network Interface: 1 RJ-45 port (10/100 Mbps)
USB Ports: 2 (1 front USB 2.0, 1 rear USB 2.0)
AI Functions:
SMD Plus: 8 channels for analog; 12 channels for IP
Perimeter Protection: 4 channels for analog
Face Recognition: 2 channels for analog; up to 10 face databases with 10,000 images
Recording Resolution: Up to 5M-N for analog channels; up to 6MP for IP channels
Maximum Incoming Bandwidth: 64 Mbps
Supported Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, DDNS, FTP, Alarm Server, P2P
Mobile Access: iOS, Android
Interoperability: ONVIF (Profile T, S, G), CGI, SDK
The Dahua DHI-NVR5208-EI is an 8-channel network video recorder from the WizSense series, designed for high-performance IP surveillance. It supports advanced AI features such as face detection, perimeter protection, and SMD Plus, ensuring intelligent and efficient video monitoring.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 32 × 1080p@30 fps or 8 × 8MP@30 fps
Maximum 384 Mbps incoming/recording/outgoing bandwidth
Supports IP cameras with resolutions up to 32 MP
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
Supports AcuPick with up to 8 channels
Supports N+M cluster and iSCSI
Video output: 1 VGA, 1 HDMI (up to 4K)
Supports ONVIF, CGI, and SDK for third-party camera access
Specifications:
Dimensions: 1U rack-mountable chassis
Material: Metal enclosure
Color Options: Black
Power Requirements: 12V DC
Other Specs:
2 SATA ports, each supporting up to 20 TB HDD
1-channel RCA audio input and output
4 alarm inputs and 2 alarm outputs
Supports various network protocols including HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Registration, iSCSI
Mobile phone access via iOS and Android
Browser support: Chrome, IE, Safari, Edge, Firefox
The Dahua DHI-NVR5208-8P-EI is an 8-channel network video recorder (NVR) from the WizSense series, designed for high-performance IP video surveillance applications. It features a built-in AI chip and advanced deep learning algorithms, supporting functions such as face recognition, perimeter protection, and Smart Motion Detection Plus (SMD Plus).
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 32 × 1080p@30 fps or 8 × 8MP@30 fps
Maximum 384 Mbps incoming/recording/outgoing bandwidth
AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
Supports AcuPick with up to 8 channels
Supports N+M cluster and iSCSI
Specifications:
Dimensions: 375 mm × 329.4 mm × 53 mm
Weight: 2.57 kg
Material: Metal casing
Color Options: Black
Power Requirements: 100–240 VAC, 47–63 Hz; Power consumption ≤10 W (without HDD); Total PoE output power: 130 W, maximum 25.5 W per port
Other Specs:
Video Input: 8 IP channels
Video Output: 1 HDMI (up to 3840 × 2160), 1 VGA (up to 1920 × 1080)
Audio Input/Output: 1/1 RCA
Alarm Input/Output: 4/2 channels
USB Ports: 2 (1 front USB 2.0, 1 rear USB 3.0)
Network Interface: 1 RJ-45 10/100/1000 Mbps Ethernet port
PoE Ports: 8 ports, 10/100 Mbps, IEEE 802.3 af/at, supports ePoE
HDD Interface: 2 SATA ports, each supporting up to 20 TB
Operating Conditions: –10°C to +55°C; 10%–93% RH
Installation: Rack or desktop
Certifications: CE, FCC
The Dahua DHI-NVR1108HS-8P-S3/H is an 8-channel network video recorder designed for small to medium-sized surveillance systems. It features 8 built-in PoE ports, supports up to 8MP resolution, and utilizes Smart H.265+ compression for efficient storage.
Key Features:
8-channel IP camera input
8 PoE ports for direct camera connection
Supports resolutions up to 8MP
Smart H.265+/H.265/Smart H.264+/H.264 video compression
1 SATA port, up to 8TB HDD capacity
1 HDMI and 1 VGA simultaneous video output
Supports ONVIF and RTSP protocols
P2P remote surveillance via mobile devices
Specifications:
Dimensions: 260 mm × 225 mm × 47.6 mm
Weight: 0.84 kg (net), 1.98 kg (gross)
Material: Metal enclosure
Color Options: Black
Power Requirements: DC 48V/53V, 2A/1.8A
Other Specs:
Network Bandwidth: 80 Mbps for access, 80 Mbps for storage, and 60 Mbps for forwarding
Decoding Capability: 1-ch@8MP (30 fps) or 4-ch@1080P (30 fps)
USB Ports: 1 front USB 2.0 port, 1 rear USB 2.0 port
Operating Temperature: –10°C to +45°C
Operating Humidity: 10%–93% (non-condensing)
Certifications: CE, FCC
The Dahua NVR2108HS-8P-I is a compact 8-channel network video recorder featuring integrated PoE ports and AI-powered WizSense technology. It supports up to 8 IP cameras, offering advanced features like face detection, perimeter protection, and SMD Plus for accurate human and vehicle classification. With support for high-resolution recording up to 12MP and efficient H.265+ compression, it's ideal for small to medium-sized surveillance systems.
Key Features:
Supports up to 8 IP camera inputs
Integrated 8 PoE ports for simplified installation
AI functions: 1-channel face detection & recognition, 2-channel perimeter protection, 4-channel SMD Plus
Supports up to 10 face databases with a total of 5,000 face images
Maximum decoding capability: 6 × 1080p@30fps
Video output: 1 HDMI (up to 4K), 1 VGA (up to 1080p)
Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Supports third-party network cameras via ONVIF and RTSP protocols
Remote access via mobile app for Android and iOS
Security baseline 2.1 compliance
Specifications:
Dimensions: 260 mm × 232.7 mm × 47.6 mm
Weight: 0.92 kg
Material: Metal casing
Color Options: Black
Power Requirements: 53V DC, 1.8A; PoE power budget: 72W (max 25.5W per port)
Other Specs:
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–93% RH
1 SATA port, supports up to 10TB HDD
Network Interface: 1 RJ-45 (10/100/1000 Mbps)
USB Ports: 2 × USB 2.0
Audio Input/Output: 1 RCA in, 1 RCA out
The Dahua DHI-XVR7208A-4K-I3 is an advanced 8-channel digital video recorder supporting multiple video formats, including HDCVI, AHD, TVI, CVBS, and IP. Equipped with WizSense AI technology, it offers features like perimeter protection, face recognition, and Smart Motion Detection Plus (SMD Plus), ensuring enhanced security and efficient video surveillance.
Key Features:
Supports 8 analog channels and up to 16 IP channels, each up to 8MP resolution
H.265+/H.265 dual-stream video compression
AI functions: 8-channel SMD Plus, 8-channel perimeter protection, 2-channel face recognition
QuickPick 2.0 for efficient target retrieval
Privacy protection with real-time face masking
Supports up to 10 face databases with 20,000 images
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Maximum incoming bandwidth of 128 Mbps
Specifications:
Dimensions: 375 mm × 287 mm × 53 mm
Weight: 1.8 kg
Material: Metal casing
Color Options: Black
Power Requirements: 12V DC, 15W (without HDD)
Other Specs:
Video Input: 8 BNC ports
Audio Input/Output: 1/1 RCA
Video Output: 1 HDMI, 1 VGA
Storage: 2 SATA ports, up to 10TB per HDD
USB Ports: 2 (1 front USB2.0; 1 back USB2.0)
Network Interface: 1 RJ-45, 10/100 Mbps Ethernet port
Operating Conditions: -10°C to +55°C; 0%–90% RH
The Dahua DH-XVR5108H-4KL-I3 is an advanced 8-channel Penta-brid digital video recorder that supports HDCVI, AHD, TVI, CVBS, and IP video inputs. Equipped with WizSense AI technology, it offers features like SMD Plus, perimeter protection, and face recognition, ensuring intelligent and efficient surveillance.
Key Features:
Supports 8 analog channels and up to 16 IP channels (each up to 8MP)
H.265+/H.265 dual-stream video compression
Full-channel AI Coding for efficient storage
SMD Plus for accurate human and vehicle detection
Perimeter protection with tripwire and intrusion detection
Face recognition with up to 10 face databases and 20,000 images
QuickPick 2.0 for efficient target retrieval
Privacy protection features
Supports IoT & POS functionalities
Specifications:
Dimensions: 325 mm × 255 mm × 55 mm
Weight: 1.2 kg
Material: Metal casing
Color Options: Black
Power Requirements: 12V DC, <10W
Other Specs:
Video Output: HDMI (4K), VGA (1080P)
Audio Input/Output: 1 RCA in, 1 RCA out
Network Interface: 1 RJ-45 port (1000 Mbps)
USB Ports: 2 (1 front USB 2.0, 1 rear USB 3.0)
HDD: 1 SATA port, up to 16TB
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH
The Dahua XVR7108/16HE-4KL-X is a high-performance 8/16-channel Penta-brid 4K Mini 1U Digital Video Recorder. It supports multiple video formats, including HDCVI, AHD, TVI, CVBS, and IP, offering flexibility for various surveillance needs. With H.265+/H.265 dual-stream video compression, it ensures efficient storage and bandwidth utilization.
Key Features:
H.265+/H.265 dual-stream video compression
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Supports 16/32 channels of IPC access, each channel up to 8MP input
Max 64/128Mbps Incoming Bandwidth
IoT & POS functionalities
Smart Search and Intelligent Video System
Specifications:
Dimensions: 325 mm × 255 mm × 55 mm
Weight: 1.45 kg
Material: Metal casing
Color Options: Black
Power Requirements: 12V DC, 10–15W
Other Specs:
Analog Camera Input: 8/16 channels, BNC
IP Camera Input: 8+8/16+16 channels, each channel up to 8MP
Audio In/Out: 8/16 channel input, 1 channel output, RCA
Video Compression: H.265+/H.265/H.264+/H.264
Resolution: Up to 4K (3840 × 2160)
Recording Rate: Main stream: 4K (1–7fps), 6MP (1–10fps), 5MP (1–12fps), 4MP/3MP (1–15fps), 1080P/720P/960H/D1/CIF (1–25/30fps)
Display Interface: 1 HDMI, 1 VGA
Network Interface: 1 RJ-45 port (1000Mbps)
USB Interface: 2 ports (1 USB 2.0, 1 USB 3.0)
Operating Temperature: –10°C to +55°C
Operating Humidity: 0%–90% RH
The Dahua NVR4108HS-8P-4KS3 is an 8-channel network video recorder from the Lite Series, featuring 8 PoE ports and support for up to 12MP IP cameras. It offers advanced AI functions, including face detection and perimeter protection, making it suitable for small to medium-sized surveillance systems.
Key Features:
Supports Smart H.265+, H.265, Smart H.264+, H.264, and MJPEG decoding formats
Maximum decoding capability: 8 × 1080p @30 fps
Maximum bandwidth: 160 Mbps incoming, 160 Mbps recording, 80 Mbps outgoing
Supports IP cameras with resolutions up to 12 MP
AI by Recorder supports 4-channel SMD Plus
AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis, and heat map
Supports ePTZ and one-click arming/disarming
Specifications:
Video Compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Audio Compression: G.711a, G.711u, PCM, G726
Video Output: 1 HDMI (up to 3840 × 2160), 1 VGA (up to 1920 × 1080)
Multi-screen Display: Main Screen: 1/4/8/9, Sub Screen: 1/4/8/9
Third-party Camera Access: ONVIF (Profile T/S/G), Panasonic, Sony, Axis, Arecont, Pelco, Canon, Hanwha
Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
Mobile Phone Access: iOS, Android
Browser Support: Chrome, IE, Safari, Edge, Firefox
Recording Modes: General, motion detection, intelligent, alarm
Backup Methods: USB device and network
Playback Modes: Instant playback, general playback, event playback, tag playback, smart playback
Alarm Inputs/Outputs: Optional (2 inputs, 1 output)
Audio Inputs/Outputs: 1-channel RCA input, 1-channel RCA output
Storage: 1 SATA port, up to 10 TB capacity
Power Supply: 53V DC, 1.25A
Power Consumption: <10W (without HDD)
Working Temperature: -10°C to +55°C (+14°F to +131°F)
Dimensions: 260 mm × 224.9 mm × 47.6 mm (10.2" × 8.9" × 1.9")
Weight: 1.2 kg (2.65 lb) (without HDD)
The Dahua DH-XVR1B08-I is an 8-channel Penta-brid digital video recorder from the Cooper-I Series, supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features AI-powered functions like SMD Plus for accurate human and vehicle detection, and AI Coding for efficient storage. With support for up to 10 IP camera inputs and Smart H.265+ compression, it offers a versatile and cost-effective surveillance solution.
Key Features:
Supports HDCVI, AHD, TVI, CVBS, and IP video inputs
Up to 10-channel IP camera input, each up to 6MP
Smart H.265+/H.265 dual-stream video compression
4-channel SMD Plus for accurate human and vehicle detection
AI Coding for optimized storage and bandwidth usage
Supports HDMI and VGA simultaneous video output
One SATA port, up to 6TB capacity
Supports mobile remote monitoring via iOS and Android
Specifications:
Dimensions: 260 mm × 236 mm × 48 mm
Weight: 1.0 kg
Material: Metal chassis
Color Options: Black
Power Requirements: DC 12V, 1.5A
Other Specs:
Video Compression: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression: G.711a, G.711u, PCM
Video Output: 1 HDMI (up to 1080p), 1 VGA
Audio Input/Output: 1-channel RCA input, 1-channel RCA output
Two-way Talk: Supported (shares audio input with the first channel)
HDD Interface: 1 SATA port, up to 6TB capacity
USB Ports: 2 USB 2.0 ports
Network Interface: 1 RJ-45 port (10/100 Mbps)
Operating Temperature: -10°C to +55°C
Operating Humidity: 10%–90% RH (non-condensing)
Certifications: CE, FCC
Compact air purifier with H13 filtration for rooms up to 40 m², efficiently removing pathogens, dust, allergens, and odours.
Perfect air purification for small rooms, children's rooms, and individual workspaces – the AF 20 air purifier cleans indoor air of allergens, pollutants, and pathogens by means of its multi-layer filter system. Other features include the active carbon fill, as well as a display to alphanumerically indicate the air quality in PM2.5 particles in µg/m³ and the air quality via a colour code. The air purifier also makes an excellent choice on account of its timer function, child safety lock, night mode and ultra-silent operation, as well as a filter efficiency of 99.95% for 0.3 µm particles and a high-quality laser sensor for the automatic mode. This means that the automatic mode and the performance level adapt automatically to the level of air pollution. Moreover, the filter has a service life of around one year, depending on the level of air pollution and the intensity with which it is used.
Key Features
High Protect 13 Filter
Dual air inlet system
Display for air quality
Quiet operation
Automatic mode
Technical Specifications
Specification
Value
Power supply (Ph/V/Hz)
1 / 100 - 240 / 50 - 60
Connected load (W)
24
Suitable room size (m²)
up to 40
Air flow rate (m³/h)
up to 220
Filter efficiency according to particle size (µm)
0.3 µm >= 99.95%
Power settings
3
Colour
White
Weight without accessories (kg)
3
Weight incl. packaging (kg)
4
Dimensions (L × W × H) (mm)
220 x 220 x 346
Get this amazing product today — order now.
Efficient air purifier for rooms up to 60 m² with advanced filtration and automatic mode.
The AF 30 air purifier with laser sensor technology, automatic mode, display, H13 filtration and activated carbon filtration removes pathogens, fine dust, allergens and odours in rooms ranging from 30 m² to 60 m² in size. Perfect air purification for medium-sized rooms, living rooms and workplaces: the AF 30 air purifier rids indoor air of allergens, pollutants and pathogens by means of its multi-layer filter system. Other features include: the activated carbon fill, as well as a display to indicate the air quality in alphanumerical terms in PM2.5 particles in µg/m³, and to indicate the air quality with a colour code, the temperature and the relative humidity. The air purifier also makes an excellent choice on account of its timer function, child safety lock, night mode and ultra-silent operation, as well as a filter efficiency of 99.95% for 0.3 µm particles and a high-quality laser sensor for the automatic mode. This means that the automatic mode and the performance level adjust automatically to the level of air pollution. Moreover, the filter has a service life of around one year, depending on the level of air pollution and the intensity of use.
Key Features
High Protect 13 Filter for bonding odours and chemical vapours.
Dual air inlet system ensures high air flow rate.
Colour display shows temperature, air humidity, and quality.
Quiet operation with smooth-running motors.
Automatic mode adapts performance to air quality.
Technical Specifications
Specification
Value
Power supply
1 / 100 - 240 / 50 - 60
Connected load
36 W
Suitable room size
up to 60 m²
Air flow rate
max. 320 m³/h
Filter efficiency
0.3 µm >= 99.95 %
Power settings
5
Colour
White
Weight without accessories
5.8 kg
Weight incl. packaging
7.5 kg
Dimensions (L × W × H)
260 x 260 x 486 mm
Get this amazing product today — order now.
The AF 50 air purifier efficiently cleans air in large rooms, removing allergens and pollutants with a 99.95% filter efficiency for particles up to 0.3 µm.
The AF 50 air purifier is designed for perfect air purification in larger rooms, living rooms, and workplaces. It effectively removes allergens, pollutants, and pathogens using its advanced multi-layer filter system. The device features an activated carbon fill and a display indicating air quality in numerical PM2.5 particles in µg/m³. The air quality is also shown in a color-coded format, along with temperature and relative humidity readings. With a filter efficiency of 99.95% for particles as small as 0.3 µm, the AF 50 offers ultra-silent operation and a robust automatic mode that adapts performance levels to the surrounding air quality. It also includes a timer function, child safety lock, and night mode, making it an excellent choice for maintaining optimal air quality at home or in the office. The filter's service life extends up to one year, depending on air pollution levels and usage intensity.
Key Features
High Protect 13 Filter for bonding odours and chemical vapours.
Dual air inlet system ensures high air flow rate.
Colour display shows temperature, air humidity, and quality.
4 rotating rollers for full mobility.
Quiet operation with smooth-running motors.
Automatic mode adapts to air quality.
Technical Specifications
Specification
Value
Power supply (Ph/V/Hz)
1 / 220 - 240 / 50 - 60
Connected load (W)
50
Suitable room size (m²)
up to 100
Air flow rate (m³/h)
max. 520
Filter efficiency (µm)
0.3 µm >= 99.95%
Power settings
5
Colour
White
Weight without accessories (kg)
9.3
Weight incl. packaging (kg)
10.5
Dimensions (L × W × H) (mm)
290 x 290 x 580
Get this amazing product today — order now.
Alexa Echo Dot (5th Generation) is a compact smart speaker featuring enhanced audio quality with clear sound and deeper bass. It seamlessly integrates Amazon Alexa for hands-free assistance and smart home control.
Key Features:
Improved audio for clear sound and deeper bass
Voice-controlled with Alexa for hands-free convenience
Compact and stylish design suitable for any room
Smart home device compatibility for seamless control
Select models feature an LED display showing time, alarms, and weather
Specifications:
Color Options: White
Power Requirements: Standard wall outlet (adapter included)
Other Specs: Hands-free control, improved bass, Alexa built-in, optional LED display (on select models)
Description: The Amazon Fire TV Stick (HD) is a streaming media player that transforms any standard TV into a smart TV. It offers fast streaming in Full HD and comes with the Alexa Voice Remote, allowing users to search and launch content using voice commands
Key Features:
50% more powerful than the previous generation for fast streaming in Full HD.
Includes Alexa Voice Remote with power and volume buttons.
Supports Dolby Atmos audio on select titles with compatible home audio systems.
Access to tens of thousands of channels, Alexa skills, and apps including YouTube, Prime Video, Disney+, Apple TV+, and HBO Max.
Live TV streaming with subscriptions to services like Sling TV and YouTube TV.
Specifications:
Dimensions: 1.18" x 0.49" x 3.38" (H x W x D)
Weight: 0.07 lbs
Material: Plastic
Color Options: Black
Power Requirements: 5W
Other Specs:
Wi-Fi 5 (802.11ac) support
8 GB storage
1 GB RAM
HDMI output
The latest Amazon Fire TV Stick 4K elevates your home cinema experience with breathtaking 4K Ultra HD streaming. Featuring Wi-Fi 6 support for smoother playback and new AI-powered search, finding your favorite movies and shows across 1.8 million titles has never been easier.
Immerse yourself in cinematic entertainment with the newest Amazon Fire TV Stick 4K. This powerful streaming stick supports brilliant 4K Ultra HD with lifelike picture quality through Dolby Vision, HDR10+, and immersive Dolby Atmos audio. With a 25% more powerful processor than the previous generation, apps start faster and navigation is fluid, ensuring a premium viewing experience every time.
The integrated Wi-Fi 6 technology provides a stable and high-speed connection even when multiple devices are connected to your router. Finding content is simplified with the AI-powered Fire TV Search; simply ask Alexa to find specific genres or actors. The included Alexa Voice Remote allows you to control your TV, soundbar, and receiver with dedicated power and volume buttons, making it the central hub for all your streaming needs.
Key Features
Vibrant 4K Ultra HD: Supports Dolby Vision, HDR10+, and HLG for stunning picture clarity and colour.
Advanced Wi-Fi 6: Enjoy smoother 4K streaming with reduced congestion and faster connectivity.
AI-Powered Search: New intelligent search functionality makes discovering new content faster and more intuitive.
Alexa Voice Remote: Control your smart home, check the weather, and navigate content using just your voice.
Massive Content Library: Access over 1.8 million movies and TV episodes from Netflix, Prime Video, Disney+, and more.
Technical Specifications
Brand
Amazon
Model
Fire TV Stick 4K (Latest Generation)
Resolution
4K Ultra HD, HDR, HDR10+, Dolby Vision
Processor
Quad-core 1.7GHz
Connectivity
Wi-Fi 6, Bluetooth 5.2
Audio Support
Dolby Atmos, 7.1 surround sound
Storage
8 GB
Elevate your home cinema with Amazon's most powerful streaming stick yet. The Fire TV Stick 4K Max (2nd Gen) features lightning-fast Wi-Fi 6E support, a boosted 2.0 GHz quad-core processor, and the all-new Ambient Experience to turn your TV into a canvas of fine art.
The Amazon Fire TV Stick 4K Max (2024) is engineered for peak performance. Supporting 4K Ultra HD, Dolby Vision, HDR10+, and immersive Dolby Atmos audio, it brings a true cinematic experience to your living room. With 16GB of internal storage—double the capacity of previous models—you can download more apps, games, and content without worrying about space.
Experience smoother streaming even when multiple devices are connected to your router, thanks to the industry-first Wi-Fi 6E support. The upgraded 2.0 GHz processor ensures faster app starts and more fluid navigation through thousands of channels and apps like Netflix, Prime Video, and Disney+. The included Alexa Voice Remote Enhanced Edition allows you to control your TV, soundbar, and receiver with dedicated buttons for recent content and live TV.
Beyond streaming, the Fire TV Ambient Experience transforms your television when not in use. Display over 2,000 gallery-quality pieces of art and photography, or stay updated with helpful Alexa widgets like calendars, weather, and smart home controls. It’s not just a streaming device; it’s the smart hub for your modern home.
Key Features
Our Most Powerful Stick: Enhanced 2.0 GHz quad-core processor for ultra-fast app launching.
Next-Gen Wi-Fi 6E: Enjoy smoother 4K streaming with lower latency, even in households with many devices.
16GB Expanded Storage: Double the storage for more apps and games compared to the standard 4K stick.
Cinematic 4K Experience: Supports Dolby Vision, HDR10+, and Dolby Atmos for stunning visuals and audio.
Fire TV Ambient Experience: Turns your TV into a smart display for art, widgets, and photos.
Alexa Voice Remote Enhanced: Includes dedicated power, volume, and navigation buttons for total setup control.
Smart Home Integration: Control lights, cameras, and more directly from your TV screen via Alexa.
The 100A Single Phase Automatic Transfer Switch (ATS) ensures seamless power transition between your main grid and backup generator or solar system for uninterrupted energy supply.
Ensure continuous power for your home or office with the 100A Automatic Transfer Switch. This high-performance device is designed to automatically switch between two power sources, such as the public utility grid and a standby generator or inverter. In the event of a power failure, the ATS detects the loss of voltage and safely transfers the load to the backup source in milliseconds, protecting your sensitive electronics from sudden outages.
Built for reliability and safety, this 2-pole ATS features a robust internal mechanism that prevents simultaneous connection of both power sources. It supports both automatic and manual operation modes, giving you full control over your electrical system. Its compact rail-mount design allows for easy integration into standard distribution boards, making it an essential component for any modern backup power setup.
Key Features
100A High Capacity: Supports heavy electrical loads for residential and commercial applications.
Dual Power Protection: Safe switching between main grid and backup (Generator/Solar).
Fast Switching Speed: Millisecond transition ensures minimal interruption to connected devices.
Dual Mode Operation: Switch easily between Automatic and Manual modes via the built-in toggle.
Compact DIN-Rail Mount: Designed for easy installation in standard electrical panels.
Durable Construction: High-quality flame-retardant materials for enhanced safety and longevity.
