Description

The Dahua DH-XVR5104HS-4KL-I3 is a 4-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP camera inputs. It features AI Coding, Smart H.265+ compression, and advanced AI functions like SMD Plus, perimeter protection, and face recognition for efficient and intelligent surveillance.

Key Features:

  • Supports HDCVI, AHD, TVI, CVBS, and IP video inputs

  • H.265+/H.265 dual-stream video compression

  • Supports all-channel AI Coding

  • Up to 8 IP camera inputs, each up to 8MP

  • Max 64 Mbps incoming bandwidth

  • 4-channel SMD Plus for analog channels

  • 4-channel perimeter protection for analog channels

  • 2-channel face recognition for analog channels

  • 2-channel QuickPick 2.0 for analog channels

  • 1-channel privacy protection for analog channels

  • IoT and POS functionalities

Specifications:

  • Dimensions: 260 mm × 237.9 mm × 47.6 mm

  • Weight: 0.96 kg

  • Material: Metal

  • Color Options: Black

  • Power Requirements: 12V DC, <7W (without HDD)

  • Other Specs:

    • Analog Camera Input: 4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

    • IP Camera Input: Up to 8 channels, each up to 8MP

    • Video Output: 1 HDMI (up to 4K), 1 VGA

    • Audio In/Out: 1/1 RCA

    • Recording Resolution: Up to 4K

    • Storage: 1 SATA port, up to 10TB

    • Network Interface: 1 RJ-45 port (10/100 Mbps)

    • USB Ports: 2 USB 2.0

    • Operating Temperature: -10°C to +55°C

    • Operating Humidity: 10%–90% (RH), non-condensing

4CH Penta-brid 4K Value/5MP Compact 1U 1HDD WizSense Digital Video Recorder

Product form

The Dahua DH-XVR5104HS-4KL-I3 is a 4-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP camera inputs. It... Read more

SKU: XVR5104HS-4KL-I3

80.000 JOD

🚚 توصلك بسرعة

    Description

    The Dahua DH-XVR5104HS-4KL-I3 is a 4-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP camera inputs. It features AI Coding, Smart H.265+ compression, and advanced AI functions like SMD Plus, perimeter protection, and face recognition for efficient and intelligent surveillance.

    Key Features:

    • Supports HDCVI, AHD, TVI, CVBS, and IP video inputs

    • H.265+/H.265 dual-stream video compression

    • Supports all-channel AI Coding

    • Up to 8 IP camera inputs, each up to 8MP

    • Max 64 Mbps incoming bandwidth

    • 4-channel SMD Plus for analog channels

    • 4-channel perimeter protection for analog channels

    • 2-channel face recognition for analog channels

    • 2-channel QuickPick 2.0 for analog channels

    • 1-channel privacy protection for analog channels

    • IoT and POS functionalities

    Specifications:

    • Dimensions: 260 mm × 237.9 mm × 47.6 mm

    • Weight: 0.96 kg

    • Material: Metal

    • Color Options: Black

    • Power Requirements: 12V DC, <7W (without HDD)

    • Other Specs:

      • Analog Camera Input: 4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect

      • IP Camera Input: Up to 8 channels, each up to 8MP

      • Video Output: 1 HDMI (up to 4K), 1 VGA

      • Audio In/Out: 1/1 RCA

      • Recording Resolution: Up to 4K

      • Storage: 1 SATA port, up to 10TB

      • Network Interface: 1 RJ-45 port (10/100 Mbps)

      • USB Ports: 2 USB 2.0

      • Operating Temperature: -10°C to +55°C

      • Operating Humidity: 10%–90% (RH), non-condensing
