Description

The Dahua DH-XVR5232AN-I3 is a 32-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features advanced AI capabilities, including perimeter protection, face recognition, and Smart Motion Detection Plus (SMD Plus). With support for up to 48 IP channels and 5MP resolution, it offers comprehensive surveillance solutions.

Key Features:

  • Supports 32 analog channels and up to 48 IP channels (each up to 6MP)

  • H.265+/H.265 dual-stream video compression

  • AI functions: 32-channel SMD Plus, 8-channel perimeter protection, 2-channel face recognition

  • QuickPick 2.0 for efficient target retrieval

  • IoT and POS functionalities

Specifications:

  • Dimensions: 375 mm × 289 mm × 53 mm

  • Weight: 1.98 kg

  • Material: Metal casing

  • Color Options: Black

  • Power Requirements: 12 VDC, <17W (without HDD)

  • Other Specs:

    • Video Input: 32 BNC ports

    • Audio Input/Output: 1/1 RCA

    • Video Output: 1 HDMI, 1 VGA

    • Storage: 2 SATA ports, up to 16TB per HDD

    • USB Ports: 2 (1 front USB 2.0; 1 rear USB 3.0)

    • Network Interface: 1 RJ-45, 10/100/1000 Mbps Ethernet port

    • Operating Conditions: –10°C to +55°C; 0%–90% RH

    • Certifications: CE, FCC

32-Channel Penta-brid 5MP Value/1080P 1U 2HDDs WizSense Digital Video Recorder

Product form

The Dahua DH-XVR5232AN-I3 is a 32-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It... Read more

SKU: XVR5232AN-I3

285.000 JOD

🚚 توصلك بسرعة

    Description

    The Dahua DH-XVR5232AN-I3 is a 32-channel Penta-brid digital video recorder supporting HDCVI, AHD, TVI, CVBS, and IP video inputs. It features advanced AI capabilities, including perimeter protection, face recognition, and Smart Motion Detection Plus (SMD Plus). With support for up to 48 IP channels and 5MP resolution, it offers comprehensive surveillance solutions.

    Key Features:

    • Supports 32 analog channels and up to 48 IP channels (each up to 6MP)

    • H.265+/H.265 dual-stream video compression

    • AI functions: 32-channel SMD Plus, 8-channel perimeter protection, 2-channel face recognition

    • QuickPick 2.0 for efficient target retrieval

    • IoT and POS functionalities

    Specifications:

    • Dimensions: 375 mm × 289 mm × 53 mm

    • Weight: 1.98 kg

    • Material: Metal casing

    • Color Options: Black

    • Power Requirements: 12 VDC, <17W (without HDD)

    • Other Specs:

      • Video Input: 32 BNC ports

      • Audio Input/Output: 1/1 RCA

      • Video Output: 1 HDMI, 1 VGA

      • Storage: 2 SATA ports, up to 16TB per HDD

      • USB Ports: 2 (1 front USB 2.0; 1 rear USB 3.0)

      • Network Interface: 1 RJ-45, 10/100/1000 Mbps Ethernet port

      • Operating Conditions: –10°C to +55°C; 0%–90% RH

      • Certifications: CE, FCC
