The D-Link DRA-1360 is a compact AC1300 dual-band mesh-enabled range extender designed to eliminate Wi-Fi dead zones and enhance wireless coverage throughout your home. It supports combined speeds of up to 1300 Mbps and integrates seamlessly with D-Link EXO routers to create a unified mesh network.
Key Features:
Dual-band Wi-Fi with speeds up to 400 Mbps (2.4 GHz) and 867 Mbps (5 GHz)
Supports D-Link Wi-Fi Mesh technology for seamless network coverage
Gigabit Ethernet port for wired device connectivity
MU-MIMO and beamforming for optimized performance
Smart Signal Indicator for optimal placement
One-touch WPS setup and D-Link Wi-Fi app support
Specifications:
Dimensions: 105 x 63.5 x 50 mm
Weight: 165 g
Material: Plastic enclosure
Color Options: Black
Power Requirements: 110–240 V AC, 50/60 Hz
Other Specs:
Wireless Standards: IEEE 802.11a/b/g/n/ac (dual-band concurrent)
Antenna: Two external antennas (2x2+2x2)
Memory: 16MB Flash, 128MB SDRAM
Security: WPA/WPA2, WPS
Operating Temperature: 0 to 40°C
Certifications: CE, FCC, UL, BSMI
Description:The Proove Multilink Adapter offers dual functionality with Bluetooth and Wi-Fi capabilities in a single, compact device. Ideal for enhancing connectivity, this adapter allows for seamless wireless data transfer and stable internet connection, making it a perfect solution for multitasking and versatile usage.
Key Features:
Combines Bluetooth and Wi-Fi connectivity in one device
Supports high-speed data transfer
Compact and portable design for easy use
Ensures stable and reliable connections
Specifications:
Material: Durable plasticColor Options: BlackConnectivity: Bluetooth and Wi-FiOther Specs: Supports dual-band Wi-Fi and Bluetooth enhanced data rate
Description:The Proove Swift BT 5.3 Adapter offers seamless Bluetooth connectivity, ensuring high-speed data transfer and stable connections. Designed for convenience, this adapter is compact and ideal for enhancing wireless communication across various devices.
Key Features:
Bluetooth 5.3 technology for efficient and fast connectivity
Compact design for portability
Supports high-speed data transfer
Ensures stable and reliable wireless connections
Specifications:
Material: Durable plasticColor Options: BlackBluetooth Version: 5.3Other Specs: Supports enhanced data rate and low energy consumption
The Archer TX20E is a high-performance Wi-Fi 6 adapter designed to upgrade your desktop or laptop for faster, more reliable wireless connections. Equipped with the latest technology, it offers improved speed, greater capacity, and reduced latency, making it ideal for gaming, streaming, and heavy internet use.
Key Features
Supports Wi-Fi 6 (802.11ax) for ultra-fast wireless speeds up to 2400 Mbps.
Dual-band connectivity on 2.4 GHz and 5 GHz frequencies for flexible network options.
Advanced OFDMA and MU-MIMO technologies to increase network efficiency.
Backward compatible with previous Wi-Fi standards (802.11a/b/g/n/ac).
Easy installation with a PCIe interface for desktop computers.
Enhanced security with WPA3 encryption to keep your data safe.
Compact design with heat dissipation features for stable performance.
Specifications
Model: Archer TX20E
Wireless Standard: IEEE 802.11ax (Wi-Fi 6), backward compatible with 802.11a/b/g/n/ac
Speed: Up to 2400 Mbps (574 Mbps on 2.4 GHz + 1800 Mbps on 5 GHz)
Frequency Bands: Dual-band (2.4 GHz and 5 GHz)
Interface: PCI Express (PCIe) x1
Antennas: 2 external high-gain antennas
Security: WPA3, WPA2, WPA
Dimensions: Approx. (depending on model design)
Weight: Around 120 grams (this is an approximate weight for typical PCIe Wi-Fi cards)
The Archer TX50E is a high-performance PCIe Wi-Fi 6 and Bluetooth 5.0 adapter designed to enhance your desktop's connectivity. Offering speeds up to 2402 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band, it ensures seamless streaming, gaming, and browsing experiences. Equipped with advanced technologies like OFDMA and MU-MIMO, it reduces latency and supports multiple devices simultaneously. The integrated Bluetooth 5.0 allows for faster and more stable connections with peripherals such as headphones, keyboards, and game controllers.
Key Features
Wi-Fi 6 (802.11ax) Support: Achieves speeds up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz bands.
Bluetooth 5.0 Integration: Offers 2× faster speeds and 4× broader coverage compared to Bluetooth 4.2.
OFDMA & MU-MIMO Technologies: Reduces latency by up to 75%, ensuring smooth gaming and streaming.
Intel Wi-Fi 6 Chipset: Delivers reliable and high-speed connections.
High-Gain Antennas: Two 5 dBi antennas enhance signal strength and coverage.
Advanced Security: Supports WPA3 for improved network protection.
Heat Sink Design: Ensures stable performance by dissipating heat effectively.
Compatibility: Supports Windows 10 (64-bit) operating systems.
Specifications
Dimensions: 95.2 × 120.8 × 21.5 mm
Weight: Approximately 120 grams
Interface: PCI Express (PCIe) x1
Chipset: Intel Wi-Fi 6 Chipset
Wireless Standards:-IEEE 802.11ax/ac/n/a (5 GHz)-IEEE 802.11ax/n/g/b (2.4 GHz)
Bluetooth Versions: 5.0, 4.2, 4.0
Security Protocols: WPA3, WPA2, WPA, WEP
Antenna Type: Two 5 dBi High-Gain Dual Band Antennas
Operating Temperature: 0°C to 40°C
Storage Temperature: -40°C to 70°C
Humidity: 10% to 90% non-condensing
System Requirements: Windows 10 (64-bit)
The D-Link NCB-C6UGRYR-305-24 is a high-performance Category 6 unshielded twisted pair (UTP) cable designed for reliable data transmission in local area networks (LANs). Featuring solid bare copper conductors and a PVC jacket, this 305-meter roll ensures optimal performance for Gigabit Ethernet applications.
Key Features:
4 pairs of unshielded twisted pair (UTP) cable
24 AWG solid bare copper conductors
PVC jacket with UL94V-0 rating
PE central cross separator for reduced crosstalk
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T applications
Compliant with TIA/EIA-568.2-D and IEC 60603-7-4 standards
Specifications:
Dimensions: Cable diameter: 5.7mm
Weight: Approximately 11.94 kg (shipping weight)
Material: Solid bare copper conductors, HDPE insulation, PVC jacket
Color Options: Gray
Power Requirements: N/A
Other Specs:
Conductor diameter: 0.520mm nominal
Insulation diameter: 0.940mm nominal
Characteristic impedance: 100Ω ±15%
Mutual capacitance: 5.6nF/100m nominal
Conductor resistance: < 9.38Ω/100m
Resistance unbalance: 5% max
Capacitance unbalance: 330pF/100m
Delay skew: < 45ns
Nominal velocity of propagation: 69%
Bending radius: < 4x cable diameter at –20°C ±1°C
Pulling force: 11.5 kg
Operating temperature range: -20°C to +70°C
The D-Link DWA-X131 is a compact Wi-Fi 6 (802.11ax) nano USB adapter designed to upgrade your computer's wireless connectivity. With support for advanced features like OFDMA, MU-MIMO, and Beamforming, it ensures efficient and reliable wireless performance, even in congested network environments.
Key Features:
Wi-Fi 6 (802.11ax) support for enhanced speed and efficiency
Maximum wireless speed up to 286 Mbps on the 2.4 GHz band
Advanced technologies: OFDMA, MU-MIMO, Beamforming, BSS Coloring
Internal high-gain antenna for improved signal reception
Compact nano design for portability and unobtrusive use
USB 2.0 interface for easy plug-and-play connectivity
Compatible with Windows 7, 10, and 11 operating systems
Specifications:
Dimensions: 16.5 x 21 x 6.8 mm
Weight: Approximately 5 grams
Material: Plastic enclosure
Color Options: Black
Power Requirements: Powered via USB port
Other Specs:
Wireless Standards: IEEE 802.11b/g/n/ax
Frequency Band: 2.4 GHz
Security Protocols: WEP, TKIP, AES, WPA, WPA2
Channel Bandwidth: 20/40 MHz
Operating Temperature: 0°C to 40°C
Storage Temperature: -20°C to 70°C
Operating Humidity: 10% to 90% (non-condensing)
Certifications: CE, RoHS
The D-Link NCB-C6FOBLR-305 is a Category 6 Foiled Twisted Pair (FTP) cable designed for outdoor networking applications. Featuring 23 AWG solid copper conductors and a UV-resistant PVC jacket, this 305-meter roll ensures reliable performance in various environmental conditions.
Key Features:
4 pairs of foiled twisted pair (FTP) cable
23 AWG solid bare copper conductors
UV-resistant PVC jacket suitable for outdoor installations
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T applications
Compliant with TIA/EIA-568.2-D standards
Specifications:
Material: Solid bare copper conductors, HDPE insulation, UV-resistant PVC jacket
Color Options: Black
Power Requirements: N/A
Other Specs:
Characteristic impedance: 100Ω ±15%
The D-Link NCB-C6SGRYR-305 is a 305-meter roll of Category 6 Foiled Twisted Pair (FTP) cable, designed for high-speed data transmission in networking environments. Featuring 23 AWG solid bare copper conductors, aluminum polyester foil shielding, and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 FTP cable for high-speed data transmission
23 AWG solid bare copper conductors
Aluminum polyester foil shielding to reduce electromagnetic interference
PVC jacket material compliant with UL94V-0
PE central cross separator for enhanced performance
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 305 meters; Cable Diameter: 7.0 mm nominal
Weight: Approximately 25 kg
Material: Solid bare copper conductors, PVC jacket
Color Options: Gray
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Conductor Diameter: 0.560 mm nominal
Insulation Diameter: 1.14 mm nominal
Drain Wire: 26 AWG
Mutual Capacitance: < 5.6 nF/100m
Characteristic Impedance: 100Ω ±15%
Nominal Velocity of Propagation: 69%
Conductor Resistance: < 9.38Ω/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Bending Radius: < 4 x Cable Diameter at –20°C ± 1°C
Pulling Force: 11.5 kg
Temperature Range: -20° to +70°C
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
The D-Link NPG-C61MET502-100 is a high-performance Cat6 FTP modular plug designed for reliable and fast data transmission. It supports both stranded and solid 24–26 AWG cables and is compatible with standard RJ45 crimping tools, making it ideal for various networking applications
Key Features:
Supports 4 twisted pairs (8P8C)
Terminates 24–26 AWG stranded and solid wires
Compatible with T568A/T568B wiring schemes
50 micro-inch gold-plated contacts for enhanced conductivity and durability
Polycarbonate housing with UL94V-2 rating
Nickel-plated bronze shielding for EMI protection
Complies with IEC60603-7-4 and ANSI/TIA/EIA-568-C.2 standards
Rated for 2000 insertion cycles
Operating temperature range: -40°C to 125°C
Specifications:
Material: Polycarbonate housing, phosphor bronze contacts with nickel and gold plating, nickel-plated bronze shield
Color Options: Transparent with metallic shield
Other Specs: Current rating: 2A; Voltage rating: 250V AC; Insulation resistance: >500 MΩ at 1000V DC/min; Contact resistance: <20 mΩ
The D-Link NCB-C6SFGRR-305 is a 305-meter Cat6 SFTP (Shielded Foiled Twisted Pair) cable designed for high-speed data transmission in networking environments. Featuring 23 AWG solid bare copper conductors, aluminum/polyester foil shielding, and tinned copper braiding, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 SFTP cable for high-speed data transmission
23 AWG solid bare copper conductors
Aluminum/polyester foil shielding with tinned copper braiding
PVC jacket material
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 305 meters; Cable Diameter: 7.6 mm nominal
Weight: Approximately 25 kg
Material: Solid bare copper conductors, PVC jacket
Color Options: Gray
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Mutual Capacitance: < 5.6 nF/100m
Characteristic Impedance: 100Ω ±5%
Conductor Resistance: < 9.38Ω/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Bending Radius: < 8 x Cable Diameter at –20°C ± 1°C
Pulling Force: 11.5 kg
Temperature Range: -20° to +70°C
Compliance: TIA/EIA-568C.2, ISO/IEC 11801, RoHS
The D-Link NCB-C6UGRYR-100 is a 100-meter roll of Category 6 unshielded twisted pair (UTP) cable, designed for high-speed data transmission in networking environments. Featuring 23 AWG solid bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
23 AWG solid bare copper conductors
PVC jacket material compliant with UL94V-0
PE central cross separator for enhanced performance
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 100 meters; Cable Diameter: 6.0 mm nominal
Weight: Approximately 3.9 kg
Material: Solid bare copper conductors, PVC jacket
Color Options: Gray
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Conductor Diameter: 0.560 mm nominal
Insulation Diameter: 0.970 mm nominal
Mutual Capacitance: < 5.6 nF/100m
Characteristic Impedance: 100Ω ±15%
Conductor Resistance: < 9.38Ω/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Bending Radius: < 4 x Cable Diameter at –20°C ± 1°C
Pulling Force: 11.5 kg
Temperature Range: -20° to +70°C
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
The D-Link NCB-C6UGRYR-305-23 is a high-performance Category 6 unshielded twisted pair (UTP) cable designed for reliable data transmission in local area networks (LANs). Featuring solid bare copper conductors and a PVC jacket, this 305-meter roll ensures optimal performance for Gigabit Ethernet applications.
Key Features:
4 pairs of unshielded twisted pair (UTP) cable
23 AWG solid bare copper conductors
PVC jacket with UL94V-0 rating
PE central cross separator for reduced crosstalk
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T applications
Compliant with TIA/EIA-568.2-D and IEC 60603-7-4 standards
Specifications:
Dimensions: Cable diameter: 5.7mm
Weight: Approximately 11.94 kg (shipping weight)
Material: Solid bare copper conductors, HDPE insulation, PVC jacket
Color Options: Gray
Power Requirements: N/A
Other Specs:
Conductor diameter: 0.520mm nominal
Insulation diameter: 0.940mm nominal
Characteristic impedance: 100Ω ±15%
Mutual capacitance: 5.6nF/100m nominal
Conductor resistance: < 9.38Ω/100m
Resistance unbalance: 5% max
Capacitance unbalance: 330pF/100m
Delay skew: < 45ns
Nominal velocity of propagation: 69%
Bending radius: < 4x cable diameter at –20°C ±1°C
Pulling force: 11.5 kg
Operating temperature range: -20°C to +70°C
The D-Link NCB-C6UGRYR1- is a Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 2 meters ,15 meters
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 50µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UGRYR1-05 is a 0.5-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 0.5 meters
Weight: Approximately 50 grams
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UYELR1-05 is a 0.5-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 0.5 meter
Material: Bare copper conductors, PVC jacket
Color Options: Yellow
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 75°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568B.2, ISO/IEC 11801, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
Operating Temperature: -20°C to 75°C
The D-Link NCB-C6UGRYR1-10 is a 10-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 10 meters
Weight: Approximately 0.35 kg
Material: Bare copper conductors, PVC jacket
Color Options: Yellow
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 50µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UGRYR1-1 is a 1-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 1 meter
Weight: Approximately 100 grams
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UYELR1-1 is a 1-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 1 meter
Material: Bare copper conductors, PVC jacket
Color Options: Yellow
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 50µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UGRYR1-3 is a 3-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 3 meters
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UGRYR1-5 is a 5-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 5 meters
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 50µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UBLUR1-1 is a 1-meter Cat6 unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 1 meter
Weight: Approximately 50 grams
Material: Bare copper conductors, PVC jacket
Color Options: Blue
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 60°C
Connector Type: RJ-45 with 50µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-C6UGRYR-305-24 is a 305-meter roll of Category 6 unshielded twisted pair (UTP) cable, designed for high-speed data transmission in networking environments. Featuring 24 AWG solid bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6 UTP cable for high-speed data transmission
24 AWG solid bare copper conductors
PVC jacket material compliant with UL94V-0
PE central cross separator for enhanced performance
Suitable for 10BASE-T, 100BASE-TX, and 1000BASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 305 meters; Cable Diameter: 5.7 mm
Weight: Approximately 11.94 kg
Material: Solid bare copper conductors, PVC jacket
Color Options: Gray
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Conductor Diameter: 0.520 mm nominal
Insulation Diameter: 0.940 mm nominal
Mutual Capacitance: 5.6 nF/100m nominal
Characteristic Impedance: 100Ω ±15%
Nominal Velocity of Propagation: 69%
Conductor Resistance: < 9.38Ω/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Bending Radius: < 4 x Cable Diameter at –20°C ± 1°C
Pulling Force: 11.5 kg
Temperature Range: -20° to +70°C
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
The D-Link NKJ-6AWHI1B21 is a high-performance Cat6A UTP keystone jack designed for 10 Gigabit Ethernet applications. It features a tool-less design with an IDC cap for easy wire management and is compatible with both 110 and Krone punch-down tools.
Key Features:
RJ45 8P8C 180° 50μ gold-plated contacts
Supports 10GBASE-T Ethernet
Tool-less termination with IDC cap
Compatible with 22–26 AWG stranded and solid wire
Universal labeling for T568A and T568B wiring schemes
Fits high-density keystone panels
Complies with ANSI/TIA/EIA 568 C.2 and ISO/IEC 11801 standards
Specifications:
Dimensions: 6.2 x 1 x 1 cm
Weight: 10 grams
Material:
Housing: ABS+PC, UL 94V-0
Contact Bracket: PC, UL 94V-2
Contacts: Phosphor bronze with nickel plating, 50μ gold-plated on plug contact area
IDC Housing: PC + Glass Fiber, UL 94V-2
IDC Terminals: Phosphor bronze with tin plating
IDC Cap: PC + Glass Fiber, UL 94V-2
PCB: FR4, UL 94V-0
Color Options: White
Power Requirements: Not applicable
Other Specifications:
Insertion force: 20N max (IEC 60603-7-4)
Retention strength: 7.7 kg between jack and plug
Operating temperature: -10°C to 60°C
Mating cycles: 750 cycles min
The D-Link NCB-6AUGRYR-305 is a high-performance Category 6A unshielded twisted pair (U/UTP) cable designed for high-speed data transmission in networking environments. Featuring 23 AWG solid bare copper conductors, a central cross separator, and a durable PVC jacket, it ensures reliable performance for Ethernet applications up to 10 Gigabits per second.
Key Features:
Category 6A U/UTP cable supporting 10GBASE-T Ethernet
23 AWG solid bare copper conductors for optimal conductivity
Central cross separator to reduce crosstalk and enhance performance
PVC jacket material compliant with UL94V-0
Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T, and 10GBASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 305 meters; Cable Diameter: 6.5 ± 0.3 mm
Weight: Approximately 11.94 kg
Material: Solid bare copper conductors, PVC jacket
Color Options: Gray
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Conductor Diameter: 0.560 mm nominal
Insulation Diameter: 0.970 mm nominal
Mutual Capacitance: < 5.6 nF/100m
Characteristic Impedance: 100Ω ±15%
Nominal Velocity of Propagation: 69%
Conductor Resistance: < 9.38Ω/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Bending Radius: < 4 x Cable Diameter at –20°C ± 1°C
Pulling Force: 11.5 kg
Temperature Range: Installation: 0° to +50°C; Operation: -20° to +70°C
Compliance: ANSI/TIA-568-C.2, ISO/IEC 11801, RoHS
The D-Link NKJ-6ASMET2B21 is a shielded Cat6A FTP keystone jack designed for high-performance 10G Ethernet applications. Its tool-less design allows for easy termination of 22–26 AWG cables, making it ideal for high-density networking environments.
Key Features:
RJ45 8P8C 180° 50μ gold-plated contacts
Tool-less termination with IDC cap
Supports 10GBASE-T Ethernet
Universal labeling for T568A and T568B wiring schemes
Fits high-density keystone panels
Complies with ANSI/TIA/EIA 568 C.2-1 and ISO/IEC 11801 standards
Specifications:
Dimensions: Standard keystone module size
Weight: Approximately 10 grams
Housing: Zinc die-cast with nickel plating
Contact Bracket: PC, UL 94V-0, transparent color
Contacts: Phosphor bronze with nickel plating, 50μ gold-plated on plug contact area
IDC Housing: PC, UL 94V-0
IDC Terminals: Phosphor bronze with tin plating
IDC Cap: PC, UL 94V-0
PCB: FR4, UL 94V-0
Color Options: Metallic Silver
Power Requirements: Not applicable
Other Specifications:
Wiring Scheme: T568A & T568B
Insertion Force: 30N max (IEC 60603-7-5)
Retention Strength: 7.7 kg between jack and plug
Operating Temperature: -10°C to 60°C
Mating Cycles: 750 cycles minimum
IDC Compatibility: Suitable for 22–26 AWG stranded and solid wire, compatible with both 110 & Krone punch-down tools
Order the D-Link Cable Cat6A UTP | High-Speed Structured Cabling in Jordan Get the reliable D-Link cable you need for high-speed data. This Cat6A U/FTP UTP Cat 6 cable features 23AWG solid copper and LSZH jacket for safe, efficient 10G Ethernet connections. Shop your 500m roll today with fast delivery in Jordan
Key Features:
4 pairs of individually foiled twisted pair (U/FTP) cable
23 AWG solid bare copper conductors
LSZH jacket for reduced smoke and toxicity in case of fire
Supports 10GBASE-T applications with a bandwidth of 500 MHz
Compliant with ANSI/TIA-568-C.2 and ISO/IEC 11801 standards
ETL verified for performance and safety
Specifications:
Cable Diameter: 7.5 ± 0.3 mm
Conductor Resistance: ≤ 9.38 Ω/100m
Mutual Capacitance: < 5.6 nF/100m
Resistance Unbalance: 5% Max
Capacitance Unbalance: 330 pF/100m
Delay Skew: < 45 ns
Characteristic Impedance: 100 ± 15 Ω
Bending Radius: Short Term: 8 × OD; Long Term: 4 × OD
Pulling Force: 11.5 kg
Operating Temperature Range: -20°C to +75°C
Color Code:
Pair 1: White-Orange Stripe and Orange
Pair 2: White-Green Stripe and Green
Pair 3: White-Blue Stripe and Blue
Pair 4: White-Brown Stripe and Brown
The D-Link NCB-6AUBLUR1-3 is a 3-meter Cat6A unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6A UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T, and 10GBASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 3 meters , 1 meter
Weight: Approximately 100 grams
Material: Bare copper conductors, PVC jacket
Color Options: Blue
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 75°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link NCB-6AUGRYR1-3 is a 3-meter Cat6A unshielded twisted pair (UTP) patch cord designed for high-speed data transmission in networking environments. Featuring 24 AWG bare copper conductors and a durable PVC jacket, it ensures reliable performance for Ethernet applications.
Key Features:
Category 6A UTP cable for high-speed data transmission
24 AWG bare copper conductors
PVC jacket material compliant with UL94V-0
Gold-plated RJ-45 connectors for optimal signal quality
Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T, and 10GBASE-T networks
Supports Power over Ethernet (PoE) applications
Specifications:
Dimensions: Length: 3 meters
Weight: Approximately 100 grams
Material: Bare copper conductors, PVC jacket
Color Options: Grey
Power Requirements: Not applicable
Other Specs:
Insulation Material: High-Density Polyethylene (HD-PE)
Heat Resistance: Up to 75°C
Connector Type: RJ-45 with 30µ” gold plating
Compliance: TIA/EIA-568C.2, UL 444, UL 758, UL 1581, RoHS
Durability: 750 mating cycles
Cable-to-Plug Tensile Strength: Minimum 89N
The D-Link DMC-300SC is a media converter designed to connect 10BASE-T/100BASE-TX copper to 100Base-FX fiber media and vice versa. Based on the IEEE 802.3 and 802.3u standards, the DMC-300SC is designed for use with multimode fiber cable utilizing the SC-Type connector.
Key Features:
Converts 10/100BASE-TX Ethernet to 100BASE-FX fiber
Supports multimode fiber with SC connector
Maximum fiber cable distance: 2 km
Auto MDI/MDI-X and auto negotiation on twisted-pair port
LED indicators for Power, Link/Activity, Full Duplex/Collision, and 100Mbps Speed
Can be used standalone or installed in DMC-1000 chassis
Specifications:
Dimensions: 120 x 88 x 25 mm
Weight: 291 g
Material: Metal enclosure
Color Options: Black
Power Requirements: External power adapter: 7.5V DC, 1.5A
Other Specs: Operating temperature: 0°C to 40°C; Storage temperature: -25°C to 70°C; Humidity: 10% to 90% non-condensing
The D-Link DGS-F1210-18PS-E is an 18-port Layer 2 Gigabit Managed PoE+ Surveillance Switch, featuring 16 PoE-enabled RJ45 ports and 2 Gigabit SFP uplink ports. Designed for surveillance and business networks, it supports long-range PoE transmission up to 250 meters, making it ideal for deploying IP cameras, wireless access points, and VoIP devices.
Key Features:
16 x 10/100/1000 Mbps PoE ports
2 x Gigabit SFP uplink ports
Supports IEEE 802.3af/at PoE standards
Total PoE power budget: 150W
Long Reach PoE up to 250 meters on 8 ports
36 Gbps switching capacity
26.8 Mpps forwarding rate
Supports VLAN, QoS, Link Aggregation, and Spanning Tree Protocols
6KV surge protection on all Gigabit Ethernet ports
User-friendly web-based management interface
Specifications:
Dimensions: 440 x 180 x 44 mm
Weight: 2.3 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 100-240V AC, 50-60Hz
Other Specs: Operating temperature: 0°C to 40°C; Operating humidity: 10% to 90% non-condensing
The D-Link DPE-302GE is a 2-Port Gigabit PoE Extender designed to extend Power-over-Ethernet (PoE) connections beyond the standard 100 meters. By daisy-chaining up to four units, it allows network and power transmission up to 500 meters, making it ideal for deploying PoE devices like IP cameras and wireless access points in hard-to-reach areas without nearby power outlets.
Key Features:
Extends PoE connections up to 500 meters via daisy-chaining
Supports IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards
Two Gigabit PoE output ports for connecting multiple devices
Plug-and-play installation with no additional power supply required
Built-in 4 kV surge protection for enhanced safety
Operates in temperatures up to 60°C, suitable for harsh environments
Multiple mounting options: built-in magnet, screw anchors, and Velcro
LED indicators for power and data flow direction
Specifications:
Dimensions: 155 x 60 x 40 mm
Weight: 154 g
Material: Plastic enclosure
Color Options: Black
Power Requirements: Powered via PoE; maximum power consumption: 3.05 W
Other Specs: Operating temperature: -10°C to 60°C; Storage temperature: -40°C to 85°C; Operating humidity: 10% to 95% non-condensing
The D-Link DGS-F1210-26PS-E is a 26-port Gigabit Smart Managed PoE+ switch designed for surveillance and enterprise networks. It features 24 PoE+ ports with a total power budget of 250W, supporting long-range PoE transmission up to 250 meters.
Key Features:
24× 10/100/1000 Mbps PoE+ ports
2× Gigabit SFP uplink ports
Supports IEEE 802.3af/at PoE standards
PoE budget: 250W
Long Reach PoE up to 250m
Switching capacity: 52 Gbps
Packet forwarding rate: 38.688 Mpps
8K MAC address table
6KV surge protection
DIP switches for VLAN, Extend, PoE, QoS modes
Web-based management interface
Specifications:
Dimensions: 440 × 180 × 44 mm
Weight: 3.2 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 100–240V AC, 50/60 Hz
Other Specs: Operating temperature: 0°C to 40°C; Operating humidity: 10% to 90% non-condensing
The D-Link DVX-2020 is a 4-port FXO expansion module designed to enhance the VoIP functionality of D-Link's DVX-2005F IP PBX systems. It allows for seamless integration of additional analog telephone lines, ensuring reliable telephony connectivity for small to medium-sized enterprises.
Key Features:
Provides 4 FXO (Foreign Exchange Office) ports for connecting analog PSTN lines
Compatible with D-Link DVX-2005F IP PBX systems
Enhances VoIP capabilities by integrating traditional phone lines
Supports seamless and reliable telephony integration
The D-Link DWA-171 is a compact USB Wi-Fi adapter that brings high-speed dual-band connectivity to your desktop or laptop. Supporting the latest 802.11ac Wave 2 standard and MU-MIMO technology, it ensures efficient data transmission, making it ideal for streaming, gaming, and browsing.
Key Features:
Dual-band Wi-Fi (2.4 GHz up to 150 Mbps; 5 GHz up to 433 Mbps)
Compliant with IEEE 802.11ac/n/g/b/a standards
MU-MIMO support for simultaneous data streams
USB 2.0 interface for easy connectivity
Supports WPA/WPA2 encryption and WPS (Wi-Fi Protected Setup)
Compact nano design for portability
Specifications:
Dimensions: 36.3 x 18.81 x 7.96 mm
Weight: 3.8 g
Material: Plastic enclosure
Color Options: Black
Power Requirements: USB-powered (5V)
Other Specs: Operating temperature: 0–40°C; Operating humidity: 10–90% non-condensing
The D-Link DGS-F1024P is a 24-port Gigabit unmanaged PoE switch designed for small to medium-sized businesses. It features 24 PoE-enabled ports and 2 Gigabit SFP uplink ports, providing a total PoE power budget of 250 watts. This switch allows for easy deployment of PoE devices such as wireless access points and IP cameras without the need for additional power sources.
Key Features:
24 x 10/100/1000 Mbps PoE ports
2 x Gigabit SFP uplink ports
Supports IEEE 802.3af/at PoE standards
Total PoE power budget of 250 watts
Plug-and-play installation with no configuration required
IEEE 802.3x Flow Control for reliable data transmission
Auto MDI/MDIX crossover for all ports
Specifications:
Dimensions: 440 x 181 x 44 mm
Weight: 2.71 kg
Material: Metal housing
Color Options: Black
Power Requirements: 100–240 V AC, 50/60 Hz
Other Specs:
Switching Capacity: 52 Gbps
Packet Forwarding Rate: 38.688 Mpps
MAC Address Table: 8K entries
Packet Buffer Memory: 4.1 Mbits
Operating Temperature: 0°C to 40°C
Storage Temperature: -20°C to 70°C
Humidity: Operating: 10% to 90% non-condensing; Storage: 5% to 95% non-condensing
Certifications: CE, FCC, RoHS
The D-Link E15 AX1500 Mesh Range Extender enhances your existing Wi-Fi network with next-generation Wi-Fi 6 technology, providing extended coverage and improved performance. Designed for device-dense environments, it ensures seamless connectivity for streaming, gaming, and smart home devices.
Key Features:
Dual-band Wi-Fi 6 (2.4GHz up to 300 Mbps; 5GHz up to 1201 Mbps)
AI Wi-Fi Optimizer and AI Mesh Optimizer for automatic network enhancements
MU-MIMO and OFDMA technologies for efficient data transmission
Supports D-Link Wi-Fi Mesh for seamless coverage with compatible devices
WPA3 wireless security for enhanced protection
Compatible with Google Assistant and Amazon Alexa for voice control
Easy setup via WPS button or EAGLE PRO AI app
Specifications:
Dimensions: 105 x 63.5 x 50 mm
Weight: 161 g
Material: Plastic enclosure
Color Options: White
Power Requirements: 100–240V AC, 50/60Hz
Other Specs: 1 x Gigabit Ethernet LAN port; 2 external foldable antennas; Operating temperature: 0–40°C; Operating humidity: 10–90% non-condensing
The D-Link DUB-E100 is a high-speed USB 2.0 Fast Ethernet adapter designed to provide a simple and efficient way to connect your desktop or notebook PC to a 10/100 Mbps Ethernet network. With its plug-and-play functionality, it eliminates the need to install internal network cards, making it ideal for users seeking quick and reliable wired connectivity.
Key Features:
USB 2.0 interface with Type A connector
RJ-45 port supporting 10/100 Mbps Ethernet
Compliant with USB 2.0 and 1.1 specifications
Supports full and half-duplex operation
Auto-negotiation for speed and duplex mode
Plug-and-play installation with hot-swappable support
Energy-saving suspend and resume functions
Bus-powered; no external power adapter required
Compatible with Windows, macOS, and Linux operating systems
Specifications:
Dimensions: Approximately 60 x 20 x 15 mm
Material: Plastic enclosure
Color Options: Black
Power Requirements: USB bus-powered (5V)
Other Specs: Supports IEEE 802.3 and 802.3u standards; LED indicators for link and activity
The D-Link NTC-001 is a professional-grade modular plug crimping tool designed for efficient installation and maintenance of structured cabling systems. It supports crimping of RJ-45, RJ-12, and RJ-11 connectors and includes integrated cutting and stripping functions, making it ideal for networking professionals and technicians.
Key Features:
Supports crimping of RJ-45 (8P8C), RJ-12 (6P6C), and RJ-11 (4P4C) connectors
All-steel construction with padded handles for durability and comfort
Built-in cable stripper with stop to ensure correct strip length
Integrated flat cable cutter and stripper
Ratchet mechanism for controlled tension and ease of operation
Corrosion-resistant black oxide finish
Specifications:
Dimensions: Length: 7.5 inches (approximately 190.5 mm)
Weight: 280 grams
Material: High-quality hardened steel with plastic handles
Color Options: Red and Black
Power Requirements: Not applicable
Other Specifications: Suitable for 22-26 AWG wires
The D-Link DPH-160W is a portable and elegant Wi-Fi phone designed for mobile communication applications. Equipped with built-in dual-band 2.4GHz and 5GHz Wi-Fi, the DPH-160W ensures stable and efficient communication in various wireless network environments. Additionally, it features Bluetooth 5.0 for easy pairing with headsets and mobile devices.
Key Features:
2" 240 x 320 color screen with intuitive user interface
Drop-safe from 1.8-meter height
Built-in dual-band Wi-Fi (2.4GHz/5GHz)
Support IEEE802.11k/v/r roaming
Support WPA / WPA2-PSK and 802.1X EAP encryption
Built-in Bluetooth 5.0 can be used to connect wireless earphone
Support vibration function
Support 16 DSS Keys and one configurable push-to-talk (PTT) button for speed dial
Up to 9 hours of talk time and up to 200 hours of standby time
Specifications:
Dimensions: 156 x 53 x 17.7 mm
Weight: 147 g (phone + battery)
Material: Plastic enclosure
Color Options: White
Power Requirements: Rechargeable 1900mAh lithium battery; DC input: 5V/2A via Type-C charging port
Other Specs: Operating temperature: 0℃~45℃; Storage temperature: -20℃60℃; Relative humidity: 1095%
The D-Link DHP-346AV PowerLine AV 4-Port Switch transforms your home's electrical wiring into a high-speed network, delivering up to 200 Mbps throughput. With four Fast Ethernet ports, it allows multiple wired devices to connect seamlessly, making it ideal for streaming, gaming, and extending internet access to areas without existing network infrastructure.
Key Features:
Utilizes HomePlug AV standard for data transmission over electrical wiring
Provides up to 200 Mbps throughput
Equipped with 4× 10/100 Mbps Ethernet ports
Supports 128-bit AES encryption for secure data transmission
Simple plug-and-play installation with push-button security setup
Port-based Quality of Service (QoS) for traffic prioritization
Power-saving mode reduces energy consumption during inactivity
Specifications:
Dimensions: 146 × 112 × 32 mm
Weight: 226 g
Material: Plastic enclosure
Color Options: White
Power Requirements: 100–240V AC, 50/60 Hz
Other Specs: Operating temperature: 0°C to 40°C; Operating humidity: 10% to 90% non-condensing
D-Link's SC-SC Multimode Fiber Patch Cords are designed for high-speed data transmission in networking environments. Featuring SC connectors on both ends and utilizing OM3 multimode fiber, these duplex cables are suitable for applications such as data centers, LANs, and telecommunications.
Key Features:
SC to SC duplex connectors
OM3 multimode fiber (50/125µm core/cladding)
Low insertion loss and high return loss
PVC or LSZH jacket options
Aqua-colored jacket for easy identification
Compliant with industry standards (EIA/TIA, IEC, ANSI, NTT, Telcordia)
Specifications:
Dimensions:
NCB-FM53D-SCSC-3: Length: 3 meters
NCB-FM51D-SCSC-1: Length: 1 meter
Material: PVC or LSZH jacket
Color Options: Aqua
Other Specs:
Fiber Type: OM3 multimode (50/125µm)
Connector Type: SC to SC
Insertion Loss: ≤0.3 dB
Return Loss: ≥30 dB
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Compliance: Telcordia GR-326, RoHS compliant
The D-Link DPH-130SE/F1 is a user-friendly business IP phone featuring a 2.4-inch color LCD display. It supports up to 4 SIP accounts and includes local 5-way conferencing, making it ideal for professional communication setups.
Key Features:
2.4” 320×240-pixel color LCD display
Supports up to 4 SIP accounts
Local 5-way conferencing
HD voice with Smart Noise Filtering Technology
Two 10/100Mbps Ethernet ports
PoE support
Adjustable multi-angle stand
Wall mountable
Supports Opus codec
Specifications:
Dimensions: 190mm x 153mm x 162mm x 42mm
Material: Plastic enclosure
Color Options: Black
Power Requirements: PoE or DC 5V/1A (power adapter optional)
Other Specs: Operating temperature: -10°C to 50°C; Operating humidity: 10% to 95%
The D-Link DWA-172 is a compact USB adapter that brings high-speed dual-band Wi-Fi connectivity to your desktop or laptop. With support for the latest 802.11ac standard and a high-gain detachable antenna, it ensures reliable connections and enhanced coverage, making it ideal for HD streaming, online gaming, and web browsing.
Key Features:
Dual-band Wi-Fi (2.4 GHz up to 150 Mbps; 5 GHz up to 433 Mbps)
Compliant with IEEE 802.11ac/n/g/b/a standards
High-gain 3 dBi external detachable antenna for improved signal strength
USB 2.0 interface for easy connectivity
Supports WPA/WPA2 encryption and WPS (Wi-Fi Protected Setup)
Compatible with Windows 8/7/Vista/XP SP3
Specifications:
Dimensions: 193 x 15.7 x 15 mm
Weight: 23.2 g
Material: Plastic enclosure
Color Options: Black
Power Requirements: USB-powered (5V)
Other Specs: Operating temperature: 0–40°C; Operating humidity: 10–90% non-condensing
The Dahua DH-S4100-8ET2GT-96-C is a Layer 2 cloud-managed PoE switch designed for efficient network management in various environments such as homes, offices, and factories.
Key Features:
10 ports: 8 × 10/100 Mbps PoE ports, 2 × 10/100/1000 Mbps uplink ports
Supports IEEE802.3af/at/bt and Hi-PoE standards
Total PoE power budget: 96 W; Port 1 supports up to 90 W
Long-distance PoE transmission up to 250 meters
Cloud management via DoLynk Care app
PoE watchdog for real-time terminal monitoring
Automatic network topology generation
Specifications:
Dimensions: 190 mm × 100 mm × 30 mm
Weight: 0.5 kg
Material: Metal casing
Color Options: Black
Power Requirements: 53 VDC, 1.81 A
Other Specs:
Switching capacity: 7.2 Gbps
Packet forwarding rate: 4.17 Mpps
MAC address table: 16K
Packet buffer size: 4 Mbit
Jumbo frame: 1,664 Bytes
Operating temperature: –10°C to +55°C
Storage temperature: –40°C to +70°C
Operating humidity: 5%–95% (RH), non-condensing
Storage humidity: 5%–95% (RH), non-condensing
Static protection: Air discharge: 8 kV; Contact discharge: 6 kV
Lightning protection: Common mode: 4 kV; Differential mode: 2 kV
The Dahua DH-IS4210-8GT-120 is a 10-port managed industrial gigabit switch featuring 8 PoE ports. Designed for industrial applications, it supports various PoE standards and offers robust performance in harsh environments.Key Features:
All-gigabit port design
Supports IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt (red port) standards
250 m long-distance PoE transmission (10 Mbps)
PoE Watchdog
Supports STP, RSTP, and ERPS
IEEE802.1Q-based VLAN configuration
Manual link aggregation and static LACP
Desktop mount and DIN-rail mountSpecifications:
Dimensions: 125 mm × 53.5 mm × 175.0 mm
Weight: Net Weight: 1.25 kg; Gross Weight: 1.52 kg
Material: Metal enclosure
Color Options: Black
Power Requirements: 53 VDC
Other Specs:
Ethernet Ports: 8 × RJ45 10/100/1000 Mbps
Optical Ports: 2 × SFP 1000 Mbps
Console Port: 1 × Console port
PoE Power: Port 1-2 ≤90 W; Port 3-8 ≤30 W; Full load ≤120 W
Switching Capacity: 20 Gbps
Packet Forwarding Rate: 14.88 Mpps
Packet Buffer Size: 4.1 Mbit
MAC Table Size: 8K
VLAN Number: 4K
Operating Temperature: –40 °C to +75 °C
Operating Humidity: 5%–95% (non-condensing)
Certifications: CE, FCC
The Dahua CS4006-4GT-60 is a 6-port cloud-managed desktop Gigabit switch featuring 4 PoE ports, designed for efficient and reliable network connectivity. It supports intelligent PoE management, cloud-based control via the DoLynk Care platform, and offers robust performance suitable for various environments.
Key Features:
6 Gigabit Ethernet ports: 4 PoE (10/100/1000 Mbps), 2 uplink (10/100/1000 Mbps)
Supports IEEE802.3af, IEEE802.3at, and Hi-PoE standards
Total PoE power budget: 60W
Intelligent PoE management with power on/off control
Cloud management via DoLynk Care platform
Layer 2 switching with 12 Gbps capacity
Fanless design for silent operation
Full metal casing with IP40 protection
Surge protection: 6 kV common mode, 0 kV differential mode
Operating temperature range: –10°C to +55°C
Specifications:
Dimensions: 130 mm × 90 mm × 26 mm
Weight: 0.29 kg
Material: Metal casing
Color Options: Black
Power Requirements: 53 VDC, 1.226 A
Other Specs:
Switching Capacity: 12 Gbps
Packet Forwarding Rate: 8.93 Mpps
MAC Address Table: 8K entries
Packet Buffer Size: 4 Mbit
Jumbo Frame Support: Up to 15K bytes
VLAN Support: Port-based VLAN, up to 32 VLANs
Management: Web-based, cloud-managed via DoLynk Care
Mounting Options: Desktop and wall mount
