Description
The Dahua NVR2216-16P-I is a 16-channel network video recorder featuring 16 PoE ports and integrated WizSense AI technology. It supports up to 12MP resolution, advanced AI functions like face detection and perimeter protection, and offers a user-friendly interface for efficient surveillance management
Key Features:
-
16-channel IP camera input
-
16 PoE ports for power and data transmission
-
Supports H.265/H.264/Smart H.265+/Smart H.264+/MJPEG video compression
-
Max decoding capability: 6 × 1080p@30fps
-
AI functions: 1-channel face detection and recognition, 2-channel perimeter protection, 4-channel SMD Plus
-
Supports up to 10 face databases and 5,000 face images
-
Simultaneous HDMI (up to 4K) and VGA video output
-
Supports ONVIF and RTSP protocols for third-party camera integration
-
Remote access via mobile app
Specifications:
-
Dimensions: 375 mm × 329.3 mm × 53 mm
-
Weight: Net weight: 2.63 kg; Gross weight: 3.91 kg
-
Material: Metal chassis
-
Color Options: Black
-
Power Requirements: 100V–240V AC, 47Hz–63Hz, 3.5A; PoE total output: 130W, max 25.5W per port
-
Other Specs:
-
Operating temperature: –10°C to +55°C
-
Operating humidity: 10%–93% RH
-
Storage: 2 SATA ports, up to 10 TB per HDD
-
Network bandwidth: 200 Mbps (access), 200 Mbps (storage), 100 Mbps (forwarding)
-
Audio input/output: 1/1 RCA
-
Alarm input/output: 4/2
